Falcon Rim Exit Device, Passage 3′ – Reliable Security Solution

Description

Falcon Lock 19-R-L-BE-D SP28 3 RHR Rim Exit Device, 3′ Passage

Falcon Lock 19-R-L-BE-D SP28 3 RHR Rim Exit Device is a Grade 1, reliable choice for light- to medium-duty door applications. Designed for both interior and exterior use, this narrow stile exit device features a sleek pushpad for easy operation, complemented by a passage lever in the stylish Dane design. With a length of 36 inches, it fits doors ranging from 2 ft. 5 in. to 3 ft. wide and is suitable for metal or wood materials. This device is equipped with hex key dogging, ensuring durability and security while maintaining a low cost for dependable performance. Ideal for commercial environments such as offices, retail spaces, and multi-family buildings, the Falcon 19 Series offers a robust solution for moderate traffic areas. It includes seven functions and four lever designs, available in three finishes, providing versatility to suit various architectural styles. The device is reversible and designed for easy installation, making it a go-to option for retrofitting existing doors. Backed by a 10-year warranty, you can trust in its long-lasting quality and functionality. Embrace the peace of mind that comes with a trusted brand-Falcon Lock ensures safety and accessibility are always at the forefront.

Rim Exit Device, Passage 3′

Grade 1 Rim Exit Device, Narrow Stile Pushpad, Hex Key Dogging, Passage Lever, Dane, 36″, Right Hand Reverse, Aluminum Painted Finish

The 19 Series narrow stile exit devices provide value and dependability on light- to medium-duty door applications. They can be mounted on interior or exterior single or double doors, where traffic is not consistently heavy.

Lowest cost most dependable light-duty exit device.

• Rim, SV
• 7 functions /4 lever designs
• 3 finishes
• 10-year warranty
• Moderate traffic
• Commercial, multi-family, office, retail
• Interior, exterior, retro-fit

Attributes

Manufacturer surcharge: 4.5%

Commercial Residential: Commercial

Device Length: 36″

Device Type: Rim

Dogging Options: Hex Key Dogging

Door Material: Metal or Wood

Door Thickness: 1-3/4 In.

Door Width: 2 Ft. 5 In. up to 3 Ft.

Finish: 689/US28

Fire Rated: No

Grade: Grade 1

Handing: Right Hand Reverse

Includes Trim: Yes

Installation: Commercial

Mechanical Function: Lever Passage

Minimum Stile Size: 1-3/4 In.

Pack Qty: 1

Pbs Options: 65172895

Physical Appearance: Narrow Stile Pushpad

Reversible: Yes

Series: 19 Series Exit Devices

Strike Standard: F570

Subtype: Rim Exit Devices

Trim Design: Dane

Trim Part No: 912L-BE-D

Trim Type: Passage Lever

Type: Exit Devices

Unit of Measure: Each

Resources

• 1490 Series Exit Devices;1590 Series Exit Devices; 1690 Series Exit Devices;1790 Series Exit Devices;19 Series Exit Devices Cut Sheet
• 19 Series Exit Device Template Index Wood Door Applications
• 19 Series Exit Devices Cut Sheet
• 19 Series Supplement to Installation Instructions
• 19, 24, 25 and XX Series Exit Devices Service Manual
• 19-V Installation Instructions
• 19-V-LBR Installation Instructions
• F-19-R & 19-R Installation Instructions
• Falcon Medium Duty Commercial Pushpads Catalog
• Medium Duty Commercial Pushpads
• Von Duprin Finishes Chart
