Falcon Rim Exit Device, Nightlatch 4′

Description

Falcon Lock F-19-R-L-NL-Q SP28 4 LHR Rim Exit Device with Nightlatch – 4′

Falcon Lock F-19-R-L-NL-Q SP28 4′ LHR Rim Exit Device is a Grade 1 fire-rated solution designed for light- to medium-duty door applications. This 48-inch narrow stile pushpad exit device combines reliability with a sleek aluminum painted finish, making it suitable for both interior and exterior single or double doors. The left-hand reverse handing and nightlatch lever provide seamless functionality for commercial environments, including multi-family residences, offices, and retail spaces. The 19 Series stands out for its value and dependability, offering a range of seven functions and four lever designs, ensuring versatility to meet various access needs. With a 10-year warranty, you can trust in its durability. This exit device accommodates doors made of metal or wood with a thickness of 1-3/4 inches, and is compatible with door widths ranging from 36 to 48 inches. Installation is straightforward, making it an excellent choice for retrofitting existing doors. The device features a rim design and includes a standard strike (F570), while the Quantum lever trim adds a touch of modernity. For added assurance, this product is fire rated, providing peace of mind in safety-critical applications. Invest in the Falcon Lock F-19-R-L-NL-Q for dependable security and accessibility.

Rim Exit Device, Nightlatch 4′

Grade 1 Fire Rated Rim Exit Device, Narrow Stile Pushpad, Nightlatch Lever, Quantum, 48″, Left Hand Reverse, Aluminum Painted Finish

The 19 Series narrow stile exit devices provide value and dependability on light- to medium-duty door applications. They can be mounted on interior or exterior single or double doors, where traffic is not consistently heavy.

Lowest cost most dependable light-duty exit device.

• Rim, SV
• 7 functions /4 lever designs
• 3 finishes
• 10-year warranty
• Moderate traffic
• Commercial, multi-family, office, retail
• Interior, exterior, retro-fit

Attributes

Manufacturer surcharge: 4.5%

Commercial Residential: Commercial

Cylinder Type: 1-1/8″ Mortise

Device Length: 48″

Device Type: Rim

Door Material: Metal or Wood

Door Thickness: 1-3/4″

Door Width: 36″ to 48″

Finish: 689/US28

Fire Rated: Yes

Fire Rating: Yes {Variable}

Grade: Grade 1

Handing: Left Hand Reverse

Includes Cylinders: No

Includes Trim: Yes

Installation: Commercial

Mechanical Function: Lever Night Latch

Pack Qty: 1

Pbs Options: 65172907, 40135713

Physical Appearance: Narrow Stile Pushpad

Reversible: Yes

Series: 19 Series Exit Devices

Strike Standard: F570

Subtype: Rim Exit Devices

Trim Design: Q – Quantum Lever

Trim Part No: 912L-NL-Q

Trim Type: Night Latch, Lever

Type: Exit Devices

Unit of Measure: Each

Resources

• 1490 Series Exit Devices;1590 Series Exit Devices; 1690 Series Exit Devices;1790 Series Exit Devices;19 Series Exit Devices Cut Sheet
• 19 Series Exit Device Template Index Wood Door Applications
• 19 Series Exit Devices Cut Sheet
• 19 Series Supplement to Installation Instructions
• 19, 24, 25 and XX Series Exit Devices Service Manual
• 19-V Installation Instructions
• 19-V-LBR Installation Instructions
• F-19-R & 19-R Installation Instructions
• Falcon Medium Duty Commercial Pushpads Catalog
• Medium Duty Commercial Pushpads
• Von Duprin Finishes Chart
