Falcon Rim Exit Device – 3′ Passage Door Hardware

Description

Falcon Lock F-19-R-L-BE-D 32D 3 LHR Rim Exit Device, Passage 3′

Falcon Lock F-19-R-L-BE-D 32D 3 LHR Rim Exit Device is a Grade 1 fire-rated solution designed for light- to medium-duty door applications. Crafted with a narrow stile pushpad and featuring a passage lever in the attractive Dane design, this exit device measures 36 inches, making it suitable for doors ranging from 2 ft. 5 in. to 3 ft. wide. The left-hand reverse configuration and satin stainless steel finish (630/US32D) add both functionality and aesthetics to any commercial environment. This versatile device can be installed on both interior and exterior metal or wood doors, providing reliable performance in settings such as offices, retail spaces, and multi-family buildings. The 19 Series exit device is noted for its dependable operation, making it the lowest cost option for light-duty use while ensuring safety during emergencies. With seven functions and four lever designs available, the Falcon F-19 offers adaptability to meet various building needs. It also comes with a 10-year warranty, underscoring its durability and quality. Whether retrofitting or installing new, this exit device is an excellent choice for anyone looking to enhance door security without compromising on style or ease of use.

Rim Exit Device, Passage 3′

Grade 1 Fire Rated Rim Exit Device, Narrow Stile Pushpad, Passage Lever, Dane, 36″, Left Hand Reverse, Satin Stainless Steel Finish

The 19 Series narrow stile exit devices provide value and dependability on light- to medium-duty door applications. They can be mounted on interior or exterior single or double doors, where traffic is not consistently heavy.

Lowest cost most dependable light-duty exit device.

• Rim, SV
• 7 functions /4 lever designs
• 3 finishes
• 10-year warranty
• Moderate traffic
• Commercial, multi-family, office, retail
• Interior, exterior, retro-fit

Attributes

Manufacturer surcharge: 4.5%

Commercial Residential: Commercial

Device Length: 36″

Device Type: Rim

Door Material: Metal or Wood

Door Thickness: 1-3/4 In.

Door Width: 2 Ft. 5 In. up to 3 Ft.

Finish: 630/US32D

Fire Rated: Yes

Fire Rating: Yes {Variable}

Grade: Grade 1

Handing: Left Hand Reverse

Includes Trim: Yes

Installation: Commercial

Mechanical Function: Lever Passage

Pack Qty: 1

Pbs Options: 65172895

Physical Appearance: Narrow Stile Pushpad

Reversible: Yes

Series: 19 Series Exit Devices

Strike Standard: F570

Subtype: Rim Exit Devices

Trim Design: Dane

Trim Part No: 912L-BE-D

Trim Type: Passage Lever

Type: Exit Devices

Unit of Measure: Each

Resources

• 1490 Series Exit Devices;1590 Series Exit Devices; 1690 Series Exit Devices;1790 Series Exit Devices;19 Series Exit Devices Cut Sheet
• 19 Series Exit Device Template Index Wood Door Applications
• 19 Series Exit Devices Cut Sheet
• 19 Series Supplement to Installation Instructions
• 19, 24, 25 and XX Series Exit Devices Service Manual
• 19-V Installation Instructions
• 19-V-LBR Installation Instructions
• F-19-R & 19-R Installation Instructions
• Falcon Medium Duty Commercial Pushpads Catalog
• Medium Duty Commercial Pushpads
• Von Duprin Finishes Chart
