Falcon Grade 1 Storeroom Lock – Durable Door Hardware

Description

Falcon Lock T581HD LAT 626 Grade 1 Storeroom Lock

Falcon Lock T581HD LAT 626 Grade 1 Storeroom Lock delivers exceptional security and durability for commercial applications. With a Grade 1 rating, this cylindrical lock is designed to withstand heavy use while ensuring reliable performance. The Latitude lever offers a sleek, modern aesthetic, complemented by a satin chrome finish for added elegance and corrosion resistance. This storeroom lock features SFIC preparation with a brown construction core and is non-handed, making it versatile for various installation needs. Its compatibility with any manufacturer’s cylinder allows for easy re-keying, ensuring your security measures can adapt as needed. The lock accommodates door thicknesses from 1-3/4″ to 2-1/4″, and the standard backset is 2-3/4″ with options for 2-3/8″ and 5″. Constructed from brass and cold-formed steel, the lock mechanism is designed for longevity, while stainless steel springs provide reliable operation. Installation is straightforward, thanks to the preassembled trim and through-bolted assembly. The lock’s UL-listed latch features a 9/16″ bolt projection, ensuring it meets high safety standards. With a limited warranty of 10 years, the Falcon T581HD LAT 626 is an excellent choice for anyone seeking dependable door hardware.

Grade 1 Storeroom Lock

Grade 1 Storeroom Cylindrical Lock, Latitude Lever, SFIC Prep with Brown Construction Core, Satin Chrome Finish, Not Handed

Can accept any manufacturer’s cylinder, and the cylinder can easily be removed for quick, easy re-keying.

• Door Thickness: 1-3/4” to 2-1/8” standard. Thin door adapter kit (A30775-000-00) available for doors thinner than 1-3/4”, please specify door thickness.
• Backset: 2-3/4” standard. 2-3/8” also available. Link (A22161-005-10) available for 5” backset.
• Mechanism: Parts constructed of brass or cold formed steel, zinc plated and dichromated for rust resistance. Springs are stainless steel.
• Attachment: Lock chassis secured to door by threaded mounting nuts. Completely preassembled outer trim and inner spindle assembly are through-bolted over chassis using (2) 10-32 screws. Adding rose and lever to inner spindle assembly completes installation.
• Handing: Locks are non-handed.
• Cylinders: Drilled with 6-pin chambers, pinned in 5. Pinning in 6 chambers available when specified, at no cost. 7-pin cylinders also available. Cylinder assemblies removable to rekey. Also available with 6 or 7-pin interchangeable core cylinders. Cylinder housings and plugs machined from solid brass. Springs are phosphor bronze. Two nickel silver keys furnished standard. Interchangeable core design is available for small format (SFIC) and large format for most manufacturers.
• Keyways: “G” keyway standard on conventional cylinders. “A” keyway standard on I/C core cylinders. Also available with some optional keyways.
• Trim: Roses are heavy wrought brass or bronze, installed over pressure cast rose inserts which are through-bolted through door. Levers are pressure cast (solid levers–no inserts) material finished to match mating parts.
• Latches: 9/16” bolt projection, UL listed with latch faceplates 2-1/4” x 1-1/8” with square corners standard. 3/4” projection, UL listed latch with 2-3/4” backset also available. Adjustable front standard.
• Strikes: 4-7/8” x 1-1/4” ANSI strike with curved lip to meet ANSI A115.2 door frame preparation standard.
• Screws: Furnished with combination screws for use in wood or metal doors and frames.
• Electrified Functions: Available in 24 VDC .185 AMP.

Attributes

Manufacturer surcharge: 4.5%

Ansi Function: F86 – Storeroom

Bolt Projection: 1/2″ Latch

Bore Hole Diameter: 2-1/8″

Box Depth Fraction: 9-1/4″

Box Height Fraction: 7″

Box Width Fraction: 3-3/4″

Commercial Residential: Commercial

Cylinder Type: SFIC Prep With Construction Core

Cylinders Present: Single Cylinder

Door Thickness: 1-3/4″ – 2-1/4″

Finish: 626/US26D

Finish Family: Matte Silver

Fire Rated: 3 Hours {A}

Fire Rating: 3 Hours {A}

Function: 581-Storeroom Lock

Function Family: Storeroom

Grade: Grade 1

Handing: Not Handed

Installation: Commercial

Keying: Keyed Different

Keys: Cut

Latch Bore Diameter: 1″

Lever Knob: Lever

Lever Knob Design Name: Latitude

Leverknob Design: LAT – Latitude Lever

Leverknob Design Family: Straight Lever

Limited Warranty: 10 Years

Lock Face Size: 2-1/4″ x 1-1/8″

Manufacturer Function: Storeroom Lock

Maximum Door Thickness: 2-1/4″

Minimum Door Thickness: 1-3/4″

Of Keys: 2

Pack Height: 3.75″

Pack Length: 9.25″

Pack Qty: 1

Pack Volume: 242.81 in³

Pack Width: 7″

Pins: 6

Product Height: 3.5″

Product Length: 7.75″

Product Width: 4.5″

Projection: 3-7/8″

Rose Escutcheon: Rose

Roseescutcheon Design: 3-1/2″ Rose Diameter

Roseescutcheon Dimensions: 3-1/2″

Screws: Combination

Series: T Series Grade 1 Cylindrical Lever Locks

Ship Weight: 5.4 lbs.

Std Keyway: A

Std Latch Backset Dim: 2-3/4″

Std Latch Number: 23981145

Std Latch Type: Dead Latch (Guarded)

Std Strike Height: 4-7/8″

Std Strike Number: 5164

Std Strike Type: ANSI Strike

Std Strike Width: 1-1/4″

Strike Dimensions: 4-7/8″ – 1-1/4″

Structure Construction Core: BRN

Subtype: Cylindrical Lock

Type: Locks, Cylinders, Cores, Keyblanks

Unit of Measure: Each
