Falcon Grade 1 Privacy Lock – Durable Door Hardware Solution

Description

Falcon Lock T301S A 626 Grade 1 Privacy Lock

Falcon T301S A 626 Grade 1 Privacy Lock offers exceptional durability and reliability, making it an ideal choice for high-traffic areas. This Grade 1 cylindrical lock features a non-keyed design, complemented by the elegant Avalon lever and standard rose, all finished in a sleek satin chrome. Engineered for heavy use, the T Series meets and exceeds ANSI/BHMA Grade 1 testing requirements, ensuring longevity and performance. Designed to accommodate various door thicknesses from 1-3/4″ to 2-1/8″, the lock is versatile, allowing for easy retrofitting with any manufacturer’s cylinder. This feature simplifies re-keying and enhances security. The lock’s robust construction includes brass or cold-formed steel components, zinc plating, and stainless steel springs for rust resistance, making it suitable for institutional applications. Key specifications include a 9/16″ bolt projection latch, ANSI strike dimensions of 4-7/8″ x 1-1/4″, and a non-handed mechanism, allowing for straightforward installation. Each lock comes with a 10-year limited warranty, ensuring peace of mind. With its combination of strength, functionality, and aesthetic appeal, the Falcon T301S A 626 Privacy Lock is a top choice for commercial environments seeking reliable security solutions.

Grade 1 Privacy Lock

Grade 1 Privacy Cylindrical Lock, Non-keyed, Avalon Lever, Standard Rose, Satin Chrome Finish, Non-Handed

The T Series extra heavy-duty Grade 1 cylindrical lock is designed to stand up to high-traffic and heavy-abuse applications. The lock can accept any manufacturer’s cylinder, and the cylinder can easily be removed for quick, easy re-keying, so retrofitting a current building is simple. The T Series is constructed with a compression spring that allows the lock to exceed ANSI/BHMA Grade 1 testing requirements. Perfect for high-use institutional applications, the T Series lock delivers by providing a solid product at a solid price.

Can accept any manufacturer’s cylinder, and the cylinder can easily be removed for quick, easy re-keying.

• Door Thickness: 1-3/4” to 2-1/8” standard. Thin door adapter kit (A30775-000-00) available for doors thinner than 1-3/4”, please specify door thickness.
• Backset: 2-3/4” standard. 2-3/8” also available. Link (A22161-005-10) available for 5” backset.
• Mechanism: Parts constructed of brass or cold formed steel, zinc plated and dichromated for rust resistance. Springs are stainless steel.
• Attachment: Lock chassis secured to door by threaded mounting nuts. Completely preassembled outer trim and inner spindle assembly are through-bolted over chassis using (2) 10-32 screws. Adding rose and lever to inner spindle assembly completes installation.
• Handing: Locks are non-handed.
• Cylinders: Drilled with 6-pin chambers, pinned in 5. Pinning in 6 chambers available when specified, at no cost. 7-pin cylinders also available. Cylinder assemblies removable to rekey. Also available with 6 or 7-pin interchangeable core cylinders. Cylinder housings and plugs machined from solid brass. Springs are phosphor bronze. Two nickel silver keys furnished standard. Interchangeable core design is available for small format (SFIC) and large format for most manufacturers.
• Keyways: “G” keyway standard on conventional cylinders. “A” keyway standard on I/C core cylinders. Also available with some optional keyways.
• Trim: Roses are heavy wrought brass or bronze, installed over pressure cast rose inserts which are through-bolted through door. Levers are pressure cast (solid levers–no inserts) material finished to match mating parts.
• Latches: 9/16” bolt projection, UL listed with latch faceplates 2-1/4” x 1-1/8” with square corners standard. 3/4” projection, UL listed latch with 2-3/4” backset also available. Adjustable front standard.
• Strikes: 4-7/8” x 1-1/4” ANSI strike with curved lip to meet ANSI A115.2 door frame preparation standard.
• Screws: Furnished with combination screws for use in wood or metal doors and frames.
• Electrified Functions: Available in 24 VDC .185 AMP.

Attributes

Manufacturer surcharge: 4.5%

Accessible: Yes

Ada Compliance: Yes

Ansi: ANSI/BHMA A156.2, Series 4000, Grade 1

Ansi Function: F76 – Privacy

Baa Qualified: Yes

Bolt Projection: 1/2″ Latch

Bore Hole Diameter: 2-1/8″

Burglar Rated: No

Commercial Residential: Commercial

Country of origin: Mexico

Cylinder Type: Non-keyed

Door Thickness: 1-3/4″ – 2-1/4″

Dust Box: None

Finish: 626/US26D

Fire Rated: 3 Hours {A}

Fire Rating: 3 Hours {A}

Function: T301-Privacy

Grade: Grade 1

Handing: Non-Handed

Installation: Commercial

Latch Bore Diameter: 1″

Leverknob Design: A – Avalon Lever

Leverknob Design Family: Curved Lever

Limited Warranty: 10 Years

Lock Face Size: 2-1/4″ x 1-1/8″

Origin: Mexico

Pack Height: 3.75″

Pack Length: 9.25″

Pack Qty: 1

Pack Volume: 242.81 in³

Pack Width: 7″

Projection: 3-1/4″

Restrictions: None

Roseescutcheon Design: Standard Rose

Roseescutcheon Dimensions: 3-1/2″ Rose Diameter

Screws: Combination

Series: T Series Grade 1 Cylindrical Lever Locks

Ship Weight: 5.5 lbs.

Std Latch Backset Dim: 2-3/4″

Std Latch Number: 23981137

Std Latch Type: Spring Latch (Unguarded)

Std Strike Height: 4-7/8″

Std Strike Number: 5164

Std Strike Type: ANSI Strike

Std Strike Width: 1-1/4″

Subtype: Cylindrical Lock

Type: Locks, Cylinders, Cores, Keyblanks

Ul Listing: A Label

Unit of Measure: Each
