Description
Sargent 827012V26D Fail Safe Electro-Mechanical 12V Mortise Lock Body, Satin Chrome
Sargent 827012V26D Fail Safe Electro Mechanical Single Cylinder 12 Volt Mortise Lock Body offers a reliable and secure locking solution designed for modern architectural needs. This lock features a fail-safe operation, ensuring that in the event of a power failure, the lock will remain unlocked, enhancing safety and accessibility. The single cylinder design operates with a 12-volt system, making it ideal for electronic access control environments. With a backset of 2-3/4 inches, this mortise lock fits standard door preparations and is equipped with a satin chrome finish, providing both durability and a sleek aesthetic that complements various architectural styles. The reversible handing allows for flexibility in installation, accommodating a range of door configurations. Included with the lock body are a faceplate strike and mounting screws, ensuring a complete and straightforward installation process. Part of the 8200 Series, this product exemplifies Sargent’s commitment to quality and innovation in door hardware. Whether securing commercial or residential properties, the Sargent 827012V26D delivers the performance and reliability that building professionals and knowledgeable homeowners demand.
Fail Safe Electro Mechanical Single Cylinder 12 Volt Mortise Lock Body with Faceplate Strike and Mounting Screws Satin Chrome Finish
Attributes
Amp Draw: 0.015 Amp
Baa Qualified: Yes
Backset: 2-3/4″ Backset
Bolt Projection: 3/4 In.
Bolt Protection: 3/4 In.
Country of Origin: Usa
Country of origin: USA
Door Thickness: 1-3/4 In.
Dust Box: None
Finish: Satin Chrome
Finish : Satin Chrome
Fire Rated: 2 Hours {B}
Fire Rating: 2 Hours {B}
Function: 70-Electrical Fail Safe
Grade: Grade 1
Handing: Reversible
Latch Type: Guarded Latch
Limited Warranty: 2 Years
Lock Face Size: 8 In. X 1-1/4 In.
Operating Voltage: 12VDC/24VDC
Origin: USA
Pack Qty: 1
Power: Hard Wired
Screws: Combination
Series: 8200 Series
Side Locked: Outside
Std Latch Type: Guarded Latch
Std Strike Height: 4-7/8 In.
Std Strike Number: 82-0110
Std Strike Type: ASA
Std Strike Width: 1-1/4 In.
Strike Height: 4-7/8 In.
Strike Number: 82-0110
Strike Type: ASA
Strike Width: 1-1/4 In.
Subtype: Electric Mortise Lock
Switch Type: None
Type: Electric Locks
Unit of Measure: Each
