Description

Adams Rite 3080E-02-0-3U-30-US32D Electrified Entry Trim

Adams Rite 3080E-02-0-3U-30-US32D Entry Trim – Electrified offers a reliable solution for securing access points in commercial settings. This electrified entry trim features a round lever design and is equipped with a cylinder hole, ensuring compatibility with a variety of Adams Rite exit devices and deadlatches. Operating at 12VDC with a fail-secure mechanism, it provides dependable access control while maintaining security. The 3080 Series Entry Trim is engineered for durability, featuring a breakaway clutching mechanism that protects the locked handle from vandalism and forced entry, regardless of direction. This design allows for easy handle changes without replacing the entire trim, thanks to shared core components across all models. With a solid construction that meets Grade 1 standards, this trim is built to withstand the rigors of daily use. Ideal for commercial applications, the 3080E is non-handed for versatile installation and comes in a sleek satin stainless steel finish (630/US32D). It does not include cylinders, allowing you to select the appropriate standard mortise cylinder with MS® cam separately. Enhance your building’s security with the reliable performance and robust design of the Adams Rite 3080E Entry Trim.

Entry Trim – Electrified

Electrified Entry Trim, 02 Round Lever, With Cylinder Hole, Universal, 12VDC, Fail Secure, Satin Stainless Steel

The 3080 Series Entry Trim provides outside activation for doors with any type of Adams Rite exit device and deadlatch. The locked handle is protected from vandalism and forced entry with a breakaway clutching mechanism.

Provides outside activation of doors that have any type of Adams Rite Exit Device.

Breakaway clutching mechanism protects the locked handle from vandalism or forced entry, in either direction. All models share the same core components, so handles can be changed without having to replace the entire trim. Solid construction meets Grade 1 standards.

• Standard Handles: The 3080-01, -02, and -03 lever handles are designed to return within ½” of the door face. Handles in the Designer Series do not have this same feature. Please verify with local code requirements to ensure compliance.
• Options: Can be ordered with or without a hole for cylinder. Order standard mortise cylinder with MS® cam separately. Order 4603 Rectifier, 4605/4606 Transformer or PS-1 Power Supply separately.

Attributes

Commercial Residential: Commercial

Cylinder Type: 1″ Mortise with MS Cam

Device Type: Trim

Electric Options: Fail Secure

Finish: 630/US32D

Finish Family: Matte Silver

Fire Rated: No

Handing: Non-Handed

Includes Cylinders: No

Installation: Commercial

Pack Qty: 1

Pbs Options: 10399484,10399342,10396402,157407299

Series: 3080 Entry Trim

Subtype: Exit Device Trim

Trim Design: 02 Lever

Trim Type: Entry Lever

Type: Exit Devices

Unit of Measure: Each

Resources

• 3080 Entry Trim Cut Sheet
• 3081/82/83 Trim Installation Instructions
• Mechanical to Electrical – Making the Jump
