Description
Von Duprin 6223 24V US32 DS Electric Strike MTS/CYL 629
Von Duprin 6223 24V US32 DS Electric Strike, Mts/Cyl 629 is a Grade 1 electric strike designed for robust security and reliability. This fail secure model operates at 24 VDC and features a sleek, fire-rated 6″ x 1-1/4″ faceplate, making it suitable for use with cylindrical or mortise locks on double doors with a closed back in hollow metal, aluminum, or wood frames.Constructed from durable stainless steel, the 6223 electric strike is built to endure the rigors of high-traffic environments. Its non-handed design provides flexibility during installation, while the adjustable strike box compensates for any misalignment of the door or frame. With a hold-force rating of 1500 lbs and UL1034 burglary-resistant certification, this strike enhances both security and traffic control. The two-piece plug connectors simplify installation and servicing, and the unit meets ANSI 156.5 Grade 1 standards for endurance and strength, boasting a dynamic strength of 70 ft-lbs and an impressive endurance rating of 1,000,000 cycles. The polished silver finish (US32) complements a variety of existing hardware, making the Von Duprin 6223 an ideal choice for commercial applications requiring both functionality and style.
Electric Strike, Mts/Cyl 629
Grade 1 Electric Strike, Fail Secure (Electrically Unlocked) 24 VDC, 6″ x 1-1/4″ Faceplate, Fire Rated, For use with Cylindrical or Mortise Locks on Double Doors (Closed Back), Hollow Metal, Aluminum, or Wood Frame, Bright Stainless Steel Finish
Von Duprin electric strikes are known for their reliability, durability and security. The 6100 Series strikes are designed to withstand abuse. Their heavy-duty stainless steel construction is UL1034 listed.
Designed for use with a variety of mortise or cylindrical locksets, as well as mortise exit devices.
The 6200 Series also provides added security and traffic control.6200 Series electric strikes can be used for retrofit applications or new construction andis designed to withstand abuse.
- Non handed design provides greater flexibility
- Strike box is adjustable to compensate for misalignment of the door or frame
- Two piece plug connectors are furnished for ease of installation and for removal during strike servicing
- ANSI 156.5 Grade 1, 1500 lb hold-force rated
- UL1034 Burglary-Resistant and UL10C Electric Strike for Fire Door
- Six finishes available to suite with existing hardware
- Durable stainless steel construction
- 24 VDC standard with 12 VDC and AC operation optional
- Meets BHMA A156.31, Grade 1 for endurance and strength
- Static strength 1300 lbs
- Dynamic strength 70 ft-lbs
- Endurance 1,000,000 cycles
Attributes
Manufacturer surcharge: 7.0%
Accessible: No
Ada Compliance: No
Amp Draw: 330mA
Application: Double Door, Closed Back
Baa Qualified: Yes
Burglar Rated: Yes
Commercial Residential: Commercial
Configuration: Centered
Country of origin: USA
Faceplate Size: 6″ x 1-1/4″
Finish: 629/US32
Finish Family: Polished Silver
Fire Rated: Yes
Fire Rating: Yes {Variable}
For Use With: Cylindrical/Mortise Locks
Frame Application: Hollow Metal, Aluminum, or Wood
Frame Depth: 4-3/4″
Function: Fail Secure
Installation: Commercial
Keeper Size: Pullman Keeper
Limited Warranty: 1 Year
Operating Voltage: 24 VDC
Origin: USA
Pack Height: 2.63″
Pack Length: 10.5″
Pack Qty: 1
Pack Volume: 161.93 in³
Pack Width: 5.88″
Product Height: 1.25″
Product Length: 6″
Product Width: 1.75″
Ramp Cut Out: 3-7/8″
Restrictions: None
Series: 6200 Series Electric Strikes
Ship Weight: 2 lbs.
Subtype: Electric Strikes
Type: Electric Strikes, Bolts, Magnets
Ul Listing: UL 10C, 1034
Unit of Measure: Each
