Description
Von Duprin 6212WF 24V US4 FS Electric Strike MTS/CYL 606
Von Duprin 6212WF 24V US4 FS Electric Strike, Mts/Cyl 606 offers a robust solution for secure access control. This Grade 1 electric strike features a fail-safe design and operates at 24 VDC, making it ideal for both cylindrical and mortise locks on single doors, specifically within wood frame applications. Its satin brass finish not only adds an aesthetic touch but also ensures durability. Designed for high-performance settings, the 6200 Series strikes are built to withstand significant abuse, boasting heavy-duty stainless steel construction that meets the stringent UL1034 burglary-resistant standards. The non-handed design allows for versatile installation, while the adjustable strike box compensates for any misalignment of the door or frame. With a 1500 lb hold-force rating and a static strength of 1300 lbs, this electric strike guarantees reliable security. It also features two-piece plug connectors for effortless installation and servicing. The strike is compliant with ANSI 156.5 Grade 1 for endurance, rated for 1,000,000 cycles, and is suitable for retrofit applications as well as new constructions. Ideal for commercial environments, the Von Duprin 6212WF electric strike seamlessly integrates with existing hardware, ensuring both security and functionality are top priorities.
Electric Strike, Mts/Cyl 606
Grade 1 Electric Strike, Fail Safe (Electrically Locked) 24 VDC, 6-3/8″ x 1-1/4″ Faceplate, For use with Cylindrical or Mortise Locks on Single Doors, Wood Frame, Satin Brass Finish
Von Duprin electric strikes are known for their reliability, durability and security. The 6100 Series strikes are designed to withstand abuse. Their heavy-duty stainless steel construction is UL1034 listed.
Designed for use with a variety of mortise or cylindrical locksets, as well as mortise exit devices.
The 6200 Series also provides added security and traffic control.6200 Series electric strikes can be used for retrofit applications or new construction andis designed to withstand abuse.
- Non handed design provides greater flexibility
- Strike box is adjustable to compensate for misalignment of the door or frame
- Two piece plug connectors are furnished for ease of installation and for removal during strike servicing
- ANSI 156.5 Grade 1, 1500 lb hold-force rated
- UL1034 Burglary-Resistant and UL10C Electric Strike for Fire Door
- Six finishes available to suite with existing hardware
- Durable stainless steel construction
- 24 VDC standard with 12 VDC and AC operation optional
- Meets BHMA A156.31, Grade 1 for endurance and strength
- Static strength 1300 lbs
- Dynamic strength 70 ft-lbs
- Endurance 1,000,000 cycles
Attributes
Manufacturer surcharge: 7.0%
Accessible: No
Ada Compliance: No
Amp Draw: 330mA
Application: Single Door
Baa Qualified: Yes
Burglar Rated: Yes
Commercial Residential: Commercial
Configuration: Centered
Country of origin: USA
Faceplate Size: 6-3/8″ x 1-1/4″
Finish: 606/US4
Finish Family: Matte Brass
Fire Rated: No
Fire Rating: No
For Use With: Cylindrical/Mortise Locks
Frame Application: Wood
Frame Depth: 4-3/4″
Function: Fail Safe
Installation: Commercial
Keeper Size: Pullman Keeper
Limited Warranty: 1 Year
Operating Voltage: 24 VDC
Origin: USA
Pack Height: 2.63″
Pack Length: 10.5″
Pack Qty: 1
Pack Volume: 161.93 in³
Pack Width: 5.88″
Product Height: 1.47″
Product Length: 6.38″
Product Width: 1.25″
Ramp Cut Out: 3-3/8″
Restrictions: None
Series: 6200 Series Electric Strikes
Ship Weight: 1.8 lbs.
Subtype: Electric Strikes
Type: Electric Strikes, Bolts, Magnets
Ul Listing: UL 10C, 1034
Unit of Measure: Each
