CRL D990DU24CR Duranodic Bronze 24″ Corner Design Partition Post
C.R. Laurence D990DU24CR Duranodic Bronze 24″ Corner Design Series Partition Post combines style and functionality, making it an excellent choice for various commercial applications. This fully assembled post features a sleek 1-1/8″ (28.6 mm) square aluminum design that is both durable and visually appealing. It is ready for immediate delivery, available in standard heights of 12″, 18″, and 24″ (305, 457, and 610 mm) and finished in a sophisticated dark bronze anodized coating. Designed to accommodate monolithic tempered glass, this post supports glazing thicknesses of 1/4″ (6 mm) with full-length channels that ensure a secure fit. The included top cap and mounting base simplify installation, while the 2″ (51 mm) square base plate provides a solid foundation. With five standard configurations-including end, center, corner, 3-way, and 4-way-this versatile post adapts seamlessly to your layout needs. Installation is straightforward thanks to the included glazing vinyl and Cat. No. 33SC clear silicone, which efficiently secures the glass within the channels. The CRL Design Series Partition Post is perfect for banks, offices, and restaurants, offering both aesthetic appeal and robust performance in a variety of environments.
Duranodic Bronze 24″ Corner Design Series Partition Post
- Stock Post Sizes, RED-E to Ship
- Standard Heights of 12″, 18″, and 24″ (305, 457, and 610 mm) Available in Four Finishes
- Five Standard Configurations – End, Center, Corner, 3-Way, and 4-Way
- Aluminum Tubing with Full Length Channels for 1/4″ (6 mm) Glass
- Top Cap and Mounting Base Included
- Use Monolithic Tempered Glass
CRL Design Series Partition Posts are very popular, available in the standard stock sizes and are ready for immediate delivery. These Posts have been used for years in banks, offices, and restaurants. A slim line profile and easy-to-install Mounting Base have made them a favorite in the industry. The glass is easily secured into the glazing channels using Cat. No. 33SC Clear Silicone. Also available in some finishes and sizes are Custom 135 Degree Posts. Each Post contains one attached Top Cap, one attached Mounting Base, and four Wood Screws for mounting.
These fully assembled Design Series Posts measure 1-1/8″ (28.6 mm) square. Post Mounting Base Plates measure 2″ (51 mm) square. Glazing Channels measure full length and rise 15/32″ (12 mm) from the post surface. Glazing Vinyl for 1/4″ (6 mm) and 3/16″ (5 mm) glass is supplied to fill glass channel.
You can also “Make Your Own” Design Series Partition Posts With CRL Components. Instructions and requirements, ” target=”_blank”>https://catalogs.crlaurence.com/CRL93G-Glass-and-Glazing/GG182/”>Instructions and requirements, parts page.
Product Warning:
The glass is easily secured into the glazing channels using Cat. No. 33SC Clear Silicone.
Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer’s video card and on how your monitor’s color is adjusted.
Attributes
Base Type: Square Flat – Mechanical
Cap Type: Flat
Compliance and Restrictions: Warning Reproductive Harm – www.p65warnings.ca.gov
Configuration: 90 Degree Corner Post
Finish/ Color:: Dark Bronze Anodized
Glazed: No
Glazing Attachment Type: U-Channel
Glazing Thickness: 1/4 in. (6 mm)
Height: 24 in. (609.6 mm)
Material: Aluminum
Series: Design
Shipping Limitations: None
Tube Size: 1-1/8 in. (28.6 mm)
Tube Type: Square
Resources
- Safety Data Sheets 701.pdf
