Dummy Trim Rigid Lever, Escutcheon with L Lever – Sargent

Description

Sargent 710-4-ETL-BSP LHR Dummy Trim Rigid Lever, LHR Left Hand, Black Suede Powder Coat

Sargent 710-4-ETL-BSP LHR Dummy Trim Rigid Lever offers a reliable and stylish solution for your door access needs. Designed with a left-hand reverse configuration, this unit features an elegant L lever and is finished in a sophisticated black suede powder coat (BSP), ensuring it complements any modern aesthetic. The trim is compatible with various Sargent exit devices, including models 8410, MD8410, MD8610, and WD8610, making it a versatile choice for your security setup. Built for durability and enhanced security, the Sargent 710 series trim is through-bolted to the chassis, providing a robust connection. It operates smoothly with a convenient one-handed lever handle, allowing for easy access. While this trim is non-handed and available in multiple functions, it specifically functions as a dummy pull, making it ideal for applications where a non-operational trim is required. The Sargent 710-4-ETL-BSP also showcases ANSI/BHMA finishes, ensuring quality and longevity. This model accommodates a door thickness of 1-3/4″, making it suitable for most standard commercial doors. Upgrade your door hardware with the Sargent 710-4-ETL-BSP and enjoy the perfect blend of functionality and aesthetic appeal.

Dummy Trim Rigid Lever, Escutcheon with L Lever, LHR Left Hand Reverse, BSP Black Suede Powder Coat (Works with (12) 8410, MD8410, MD8610 and WD8610)

Notice: The info below is not item specific.

The 700 series ET control is sold separately from the exit device and can be used with 8888 & 8810 exit device. The trim is non handed and is through bolted to the chassis for greater security and durability. Available in 7 functions and Sargent studio, coastal and standard lever designs to accommodate most requirements.

Features:

• ANSI/BHMA Finishes
• Easy operating lever handle allows convenient one hand operation
• ET trim is not available in 32 or 32D
• Stainless steel levers are available

Functions:

• 04: Key retracts latch #34 cylinder supplied. ANSI 03
• 10: No O/S operation or cylinder (pull only). ANSI 02
• 28: Passage only (no cylinder). ANSI 15
• 63: Key outside unlocks/locks thumbpiece #34 cylinder supplied. ANSI 05
• 62: Key unlocks thumbpiece, thumbpiece retracts latch/thumbpiece relocks when key is removed #34 cylinder supplied. ANSI 06
• 66: Key outside retracts latch; key inside unlocks/locks O/S trim O/S #34 and I/S #44. ANSI 07
• 73: Electrified ET trim – fail safe power off, unlocks lever (no cylinder)
• 74: Electrified ET trim – fail secure power off, locks lever (no cylinder)
• 75: Electrified ET trim – fail safe power off, unlocks lever, key retracts latch #34 cylinder supplied
• 76: Electrified ET trim – fail secure power off, locks lever, key retracts latch #34 cylinder supplied

Finishes:

• 0-3/605 – Bright brass, clear coated
• 0-4/606 – Satin brass, clear coated
• 0-9/611 – Bright bronze, clear coated
• 1-0/612 – Satin bronze, clear coated
• 10B/613 – Dark oxidized satin bronze, oil rubbed
• 10BE/613E – Dark oxidized satin bronze, equivalent
• 10BL/613L – Dark oxidized satin bronze clear coated
• 20D/624 – Dark statuary bronze lacquered
• 2-6/625 – Bright chrome plated
• 26D/626 – Satin chrome plated
• 3-2/629 – Bright stainless steel
• 32D/630 – Satin stainless steel
• BSP – Black suede powder coat
• WSP – White suede powder coat

Attributes

Alternate Codes: 710-4-ETL-BSP LHR, 7104ETLBSPLHR

Category: Panic Devices & Exit Alarms, Panic Device Trims

Door Application: Panic Devices & Exit Alarms

Door Thickness: 1-3/4″

Finish Code: BSP

Finish Color: Black Suede Powder Coat

Function: Dummy Pull

Handing: Left Handed Reverse
