Dummy Trim Rigid Lever, Escutcheon with J Lever, RHR Right Hand Reverse, Satin Chrome

Description

Sargent 710-4-ETJ-26D RHR Dummy Trim Rigid Lever, J Lever, RHR Right Hand, Satin Chrome 626/US26D

Sargent 710-4-ETJ-26D RHR Dummy Trim Rigid Lever offers a seamless blend of functionality and style for your panic device or exit alarm applications. Designed specifically for right-hand reverse installations, this dummy trim is compatible with Sargent models 8410, MD8410, MD8610, and WD8610. Its robust construction features through bolting to the chassis, ensuring enhanced security and durability over time. The lever handle operates smoothly, allowing for convenient one-handed operation, making it an ideal choice for high-traffic areas. This trim is available in a striking Satin Chrome finish (626), offering a modern aesthetic that complements various architectural styles. The versatile design accommodates seven different functions, providing options like key retractable latches or passage-only modes, suited for a variety of security needs. With a door thickness of 1-3/4″, the Sargent 710-4-ETJ-26D is built to meet industry standards for performance. Its non-handed trim means installation flexibility, and the stainless steel levers available enhance its resilience against wear. Whether upgrading existing hardware or installing new systems, this dummy trim is an excellent choice for professionals seeking reliability and sophistication in security hardware.

Dummy Trim Rigid Lever, Escutcheon with J Lever, RHR Right Hand Reverse, 626/US26D Satin Chrome (Works with (12) 8410, MD8410, MD8610 and WD8610)

Notice: The info below is not item specific.

The 700 series ET control is sold separately from the exit device and can be used with 8888 & 8810 exit device. The trim is non handed and is through bolted to the chassis for greater security and durability. Available in 7 functions and Sargent studio, coastal and standard lever designs to accommodate most requirements.

Features:

• ANSI/BHMA Finishes
• Easy operating lever handle allows convenient one hand operation
• ET trim is not available in 32 or 32D
• Stainless steel levers are available

Functions:

• 04: Key retracts latch #34 cylinder supplied. ANSI 03
• 10: No O/S operation or cylinder (pull only). ANSI 02
• 28: Passage only (no cylinder). ANSI 15
• 63: Key outside unlocks/locks thumbpiece #34 cylinder supplied. ANSI 05
• 62: Key unlocks thumbpiece, thumbpiece retracts latch/thumbpiece relocks when key is removed #34 cylinder supplied. ANSI 06
• 66: Key outside retracts latch; key inside unlocks/locks O/S trim O/S #34 and I/S #44. ANSI 07
• 73: Electrified ET trim – fail safe power off, unlocks lever (no cylinder)
• 74: Electrified ET trim – fail secure power off, locks lever (no cylinder)
• 75: Electrified ET trim – fail safe power off, unlocks lever, key retracts latch #34 cylinder supplied
• 76: Electrified ET trim – fail secure power off, locks lever, key retracts latch #34 cylinder supplied

Finishes:

• 0-3/605 – Bright brass, clear coated
• 0-4/606 – Satin brass, clear coated
• 0-9/611 – Bright bronze, clear coated
• 1-0/612 – Satin bronze, clear coated
• 10B/613 – Dark oxidized satin bronze, oil rubbed
• 10BE/613E – Dark oxidized satin bronze, equivalent
• 10BL/613L – Dark oxidized satin bronze clear coated
• 20D/624 – Dark statuary bronze lacquered
• 2-6/625 – Bright chrome plated
• 26D/626 – Satin chrome plated
• 3-2/629 – Bright stainless steel
• 32D/630 – Satin stainless steel
• BSP – Black suede powder coat
• WSP – White suede powder coat

Attributes

Alternate Codes: 710-4-ETJ-26D RHR, 7104ETJ26DRHR

Category: Panic Devices & Exit Alarms, Panic Device Trims

Door Application: Panic Devices & Exit Alarms

Door Thickness: 1-3/4″

Finish Code: 626

Finish Color: Brushed Chrome, Satin Chrome

Function: Dummy Pull

Handing: Right Handed Reverse
