DL3200 Single Cyl Deadbolt by Corbin Russwin – Durable Security Solution

Description

Corbin Russwin DL3213 626 LC DL3200 Single Cylinder Deadbolt

Corbin Russwin DL3213 626 LC DL3200 Single Cyl Deadbolt combines robust security with ease of installation, making it an ideal choice for various applications. This cylindrical deadlock features a solid steel deadbolt with a hardened, free-spinning steel pin insert and boasts a 1″ throw, ensuring superior protection against unauthorized access. Certified to 156.5 Grade 1 standards, the DL3200 is designed for long-lasting durability and reliability. The deadbolt is suitable for standard door thicknesses of 1-3/4″ and offers optional thicknesses to accommodate diverse installations. With backsets available in 2-3/4″ or 2-3/8″, the DL3213 is designed for standard 161 door prep, allowing for seamless integration into existing door hardware. The non-handed design simplifies installation, while the option for pyramid cylinders enhances security features. Additional keying options such as master keying and visual key control provide versatility for various security needs. The deadbolt is UL listed for use with fire-rated doors, adding an extra layer of safety. With a one-year limited warranty, the Corbin Russwin DL3213 ensures peace of mind for building professionals and homeowners alike, making it a smart investment in door security.

DL3200 Single Cyl Deadbolt

DL3200 Series Cylindrical Deadlock, Single Cylinder, Less Cylinder, Satin Chrome

Corbin Russwin is pleased to introduce the DL2200 and DL3200 cylindrical deadlocks. These easy to install deadlocks feature a solid steel deadbolt – with a hardened, free spinning, steel pin insert – and a 1″ throw. Ideal for a variety of applications, the DL2200 is certified to 156.5 Grade 2 standards and the DL3200 is certified to 156.5 Grade 1 standards. FeaturesSolid steel deadbolt with a hardened, free spinning, steel pin insert and a 1″ throw1-3/4″ door thickness standard; additional door thicknesses offeredAvailable in 2-3/4″ or 2-3/8″ backsetsStandard 161 door prepPyramid cylinders optionalUL listed for use with Fire Rated doors

Non-handed cylindrical deadlock.

• Handing Non-handed.
• Door Thickness Standard: 1-3/4″ (44mm). Optional door thicknesses available
• Backset Standard: 2-3/4″ (70mm) Optional: 2-3/8″ (60mm)
• Front Standard: brass or stainless steel, 2-1/4″ (57mm) x 1-1/8″ (29mm). Optional: 1″ width; see Quick Codes.
• Deadbolt 1″ throw, solid steel deadbolt with hardened, free spinning, steel pin insert.
• Strike Standard; 2-3/4″ (70mm) x 1-1/8″ (29mm). Optional strikes and wrought boxes available; see Strikes, this page.
• Cylinder Standard: brass, 6-pin, L4 keyway, 0-bitted. Security cylinder optional; see Quick Codes.
• Keys Two nickel silver standard.
• Keying Features Available Master keying Construction master keying Security Visual key control Concealed key control
• Warranty One-year limited.

Attributes

Finish: 626/US26D

Function: Single Cylinder Deadbolt

Series: DL3200 Series Cylindrical Deadlocks

Subtype: Deadbolts

Type: Locks, Cylinders, Cores, Keyblanks

Resources

• DL2200/DL3200 Installation Instructions
• DL3200 Series Cylindrical Deadlocks Cut Sheet
• Padlocks and Deadlocks Catalog
