Cylindrical Storeroom Lock by TownSteel

Description

TownSteel CEI-86-S-626 Cylindrical Storeroom Lock

TownSteel CEI-86-S-626 Cylindrical Storeroom Lock is a Grade 1, non-clutched extra heavy-duty lockset that delivers exceptional security and durability, making it ideal for high-traffic environments such as schools, universities, office buildings, and industrial complexes. This storeroom function lock features the elegant Sentinel lever design and is prepared for SFIC, ensuring versatile access control options. Constructed to meet ANSI/BHMA A156.2-2011 4000 Series Grade 1 standards and UL10C 3-hour rating, the CEI-86-S-626 includes an innovative internal spring mechanism that prevents lever sag, maintaining an attractive low-profile appearance with its self-adjustable stainless steel faceplate. This lockset accommodates door thicknesses ranging from 1-3/4″ to 2″ and has a standard backset of 2-3/4″, with a robust stainless steel latch bolt offering a ½” throw for reliable operation. TownSteel’s commitment to quality is evident in this versatile cylindrical lock, which is designed for a wide range of applications, ensuring safety and security without compromising aesthetics. Ideal for institutional and commercial settings, the CEI-86-S-626 provides peace of mind and dependable performance, making it a smart choice for professionals in the field.

Cylindrical Storeroom Lock

Grade 1, Non-Clutched Extra Heavy Duty Cylindrical Lockset, Storeroom Function, Sentinel Lever, SFIC Prep, Satin Chrome

The CE Series Cylindrical Lock is designed for High Traffic commercial areas such as schools, universitis, office buildings, and industrial complexes. The CE iscertified ANSI/BHMA A156.2-2011 4000 Series Grade 1 and UL10C 3 Hour Rated. Featuring an internal spring design that mitigates lever sag, and allows for an aesthetically pleasing low projection rose. The CE series is available with a standard Schlage C keyway as well as SFIC, Schlage LFIC, Corbin LFIC, and TownSteel High Security Cylinders.

Designed for multiple applications from institutional to high-traffic commercial areas.

TownSteel Cylindrical Locks are offered in a variety of series, including CE, CD, CS and CSRC. This offering spans a multitude of applications including schools, universities, office buildings, industrial complexes and more.

CE Series

• Door Thickness: 1-3/4″ – 2″
• Backset: 2-3/4″ Standard, 5″ Optional
• Latch Bolt: Stainless Steel, 1/2″ throw
• Faceplate: Self-adjustable, 1-1/8″ x 2-1/4″ Stainless Steel

CDC Series

• Door Thickness: 1-3/8″ – 2″
• Backset: 2-3/4″ Standard, 2-3/8″, 3-3/4″, 5″ Optional
• Latch Bolt: Stainless Steel, 1/2″ (12.7mm) throw, deadlocking on keyed functions. Anti-friction fire door latch with 3/4″ (19mm) throw available upon request
• Faceplate: Forged brass or Stainless Steel, 1-1/8″ X 2-1/4″ (29mm X 57mm) square corner, beveled.

Attributes

Manufacturer surcharge: 14.0%

Cylinder Type: SFIC Prep Less Core

Door Thickness: 1-3/4 In. – 2 In.

Finish: 626/US26D

Function: 86-Storeroom

Grade: Grade 1

Handing: Not Handed

Leverknob Design: S – Sentinel Lever

Pack Qty: 1

Series: TownSteel Cylindrical Locks

Std Latch Backset Dim: 2-3/4 In.

Subtype: Cylindrical Lock

Type: Locks, Cylinders, Cores, Keyblanks

Unit of Measure: Each

Resources

• 2024 TownSteel Price Book
• TownSteel CDC/CD Series Catalog
• TownSteel CE Series Catalog
• TownSteel CS Series Catalog
• TownSteel CSRC Series Sell Sheet
