Corbin Russwin ML2065 LWVN 626 M31 V21 RH Dormitory Mortise Lock Trim
Corbin Russwin ML2065 LWVN 626 M31 V21 RH Dormitory Mortise Lock Trim offers an exceptional blend of security and functionality tailored for high-traffic environments. As a Grade 1 mortise lock, this model is engineered for commercial, institutional, industrial, and government applications, ensuring reliability and durability in demanding settings. Constructed from heavy-gauge steel, the lock features a patented Quick Reversible latchbolt and a robust 1″ stainless steel deadbolt, maximizing security. The Lustra (Wrought) lever design paired with the VN Indicator Escutcheon provides a sleek and modern aesthetic, while the satin chrome finish enhances its corrosion resistance. This lock is specifically designed for right-handed doors and is compatible with standard door thicknesses of 1-3/4″. With a backset of 2-3/4″ and a heavy-duty lockcase measuring 5-7/8″ x 4″ x 15/16″, the ML2065 is ideally suited for various applications, from offices to hotels. The product comes with two nickel silver keys and includes a 10-year warranty, demonstrating Corbin Russwin’s commitment to quality. Additionally, it meets FF-H-106C federal standards and is UL listed, providing peace of mind for users in high-security environments.
Dormitory Mortise Lock Trim
Grade 1 Dormitory or Entrance Mortise Lock Trim, Lustra (Wrought) Lever, VN Indicator Escutcheon, Conventional Cylinder, Satin Chrome Finish, Right-Handed
The ML2000 Series Grade 1 Mortise Lock is designed to meet the rigors of high trasffic commercial, institutional, industrial and government applications. Constructed of heavy gauge steel, the lockbody features our patented quick reversible latchbolt and a 1″ stainless steel deadbolt. A wide variety of trim designsand functions with a 10 year warranty lend to the ML2000’s versatility and reliability, making it the ideal choice for use in offices, schools, hospitals, hotels and other high use applications.
The ML2000 series is a Grade 1 mortise lock designed to meet the rigors of high-traffic commercial, institutional, industrial and government applications.
The ML2000 Series is constructed of heavy-duty gauge steel and features a lockbody with the patented Quick Reversible latchbolt.A wide variety of trim designs and functions and a 10-year warranty lend to the ML2000’s versatility and reliability, making it the ideal choice for use in offices, schools, hospitals, hotels and other high-use applications.
- Handing: Handed; quick reversible. The lockset can be re-handed without disassembling the lock case.
- Door Thickness: 1-3/4″ (44mm) standard. Optional door thicknesses available.
- Backset: 2-3/4″ (70mm).
- Lockcase: Heavy-gauge steel, 5-7/8″ (149mm) x 4″ (102mm) x 15/16″ (24mm). Optional: non-ferrous lockcase for corrosion resistance.
- Front: Heavy-gauge steel, 8″ (203mm) x 1-1/4″ (32mm) x -3/32″ (2mm). Accommodates flat doors and doors beveled 1/8″ (3mm) in 2″ (51mm). Furnished 1-1/16″ (27mm), optional D138, wide for 1-3/8″ (35mm) doors.
- ArmoredFront: Wrought brass, bronze or stainless steel attached by machine screws to lockcase front. ML2000HS & ML2000VR utilizes security Torx® screws.
- Latchbolt: 2-piece mechanical with anti-friction insert, 5/8″ (16mm) x 1″ (25mm) x 3/4″ (19mm) throw.
- Keys: Two nickel silver standard.
- Federal: Meets FF-H-106C.
- Environmental Product Declaration: (EPD) certified
Attributes
Ansi: A156.13, Series 1000
Ansi Function: F13 – Dormitory
Baa Qualified: Yes
Base Series: ML2000
Commercial Residential: Commercial
Country of origin: USA
Cylinder Type: Conventional Cylinder
Door Thickness: 1-3/4″
Finish: 626/US26D
Finish Family: Matte Silver
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: 65-Dormitory or Entrance
Grade: Grade 1
Handing: Right-Handed
Installation: Commercial
Keying: 0 Bitted
Keys: Blank
Leverknob Design: LW – Lustra (Wrought) Lever
Limited Warranty: 10 Years
Lock Face Size: 8″ x 1-1/4″
Of Keys: 2
Origin: USA
Pack Height: 4.5″
Pack Length: 10″
Pack Qty: 1
Pack Width: 7.5″
Pins: 6
Roseescutcheon Design: VN Indicator Escutcheon
Series: ML2000 Series Mortise Locks
Ship Weight: 4 lbs.
Std Keyway: L4
Subtype: Trim Kits & Packs
Type: Locks, Cylinders, Cores, Keyblanks
Ul Listing: UL Listed
Unit of Measure: Each
Unit of Measure 2: Case
Unit of Measure 2 Qty: 6
