CINETTO PS40.2 Coplanar Sliding System – Richelieu

Description

Richelieu WEBKIT1214147 CINETTO PS40.2 Coplanar Sliding System

Richelieu WEBKIT1214147 Cinetto PS40.2 Coplanar Sliding System offers an innovative solution for large cabinet doors, accommodating weights of up to 132 lb (60 kg) each. This flexible system can seamlessly handle one, two, or three wood doors, making it ideal for various applications such as wardrobes, pantries, and large storage millwork in both residential and commercial environments. Engineered for convenience, the Cinetto PS40.2 features adjustable surface mount hardware and comes with a soft-close mechanism, ensuring a smooth and quiet operation. Its design requires no special cabinet fabrication, simplifying installation. The system is available in two elegant track finishes-silver and stainless steel effect anodized aluminum-allowing for versatility in design aesthetics. The product supports door widths ranging from 35 to 70 7/8 inches and accommodates heights up to 9 feet 10 inches, making it suitable for larger spaces. It is crucial to use a door straightener or stiffener to enhance the rigidity of the doors. With a load capacity that ranges between 99.2 to 220 lb, the Richelieu Cinetto PS40.2 is a robust choice for those seeking functionality without compromising style.

CINETTO PS40.2 Coplanar Sliding System

Cinetto PS40.2 Coplanar Sliding System for large cabinet doors weighing up to 132 lb (60 kg) each.

Features:
– Flexible system for one, two, or three wood doors
– Surface mount hardware, adjustable
– Soft-close mechanism included
– No special cabinet fabrication is required
– Two types of track finishes: silver and stainless steel effect anodized aluminum

This is an ideal solution for closets, pantries, large storage millwork, and wardrobes/armoires in residential and commercial applications.

IMPORTANT: We recommend that you use a door straightener/stiffener to make the door more rigid.

Attributes

Ship via: No UPS – Common Carrier Only

” Optional” Door Width: 890 to 1 800 mm

Adjustable: Yes

Application: Wardrobe, Pantry, Cabinet, Storage

Brand: CINETTO

Brand Model: Cinetto PS40

Detailed Door Movement: Bypassing

Door Height: 3 000 mm

Door Material: Wood

Door Movement: Coplanar

Door Position: Full Overlay, Inset/Inlay

Door Thickness: Min. 19 mm

Door Thickness Including the Handle: 16 to 55 mm

Door Width: 888 to 1 800 mm

Finish: Satin Aluminum

Height Clearance: 131 mm

Length – Overall Dimensions: 96 1/2 in*

Load Capacity: 99.2 to 220 lb*

Manufacturing Material: Aluminum

Number of Doors: 2

Opening: Towards the right / Towards the left

Overall Length: 2 450 mm

PS40 Opening: Towards the left / Towards the right

Product #: WEBKIT1214147

Product number: WEBKIT1214147

Product №: WEBKIT1214147

Roller Position: Upper

Roller Type: Ball Bearing

Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84″ or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.

Soft- Close Type: One-Way Operation

Soft- Closing: Yes

Track Finish: Satin Aluminum

Track Material: Anodized Aluminum

Weight Capacity per Door: 60 kg

Resources

• Door Width Option
• Door Width Option
• Door width “option”
• Door width “option”
• Instructions
• Product Info
• Pull Handle Position
