Description
Richelieu WEBKIT1213686 CINETTO PS40.1 Coplanar Sliding System
Richelieu WEBKIT1213686 CINETTO PS40.1 Coplanar Sliding System offers a sophisticated solution for managing large cabinet doors, accommodating weights up to 132 lb (60 kg) each. This flexible system supports the installation of one, two, or three wooden doors, making it ideal for closets, pantries, and expansive storage millwork in both residential and commercial settings. Featuring recessed mount hardware that is adjustable, the Cinetto PS40.1 system ensures a clean and streamlined appearance. The soft-close mechanism adds a touch of elegance and safety, preventing slamming and ensuring quiet operation. There is no need for special cabinet fabrication, simplifying installation. Available in two attractive track finishes-silver and stainless steel effect anodized aluminum-the system allows you to choose a look that complements your design aesthetic. With a door height capacity of up to 9 ft 10 in and a thickness ranging from 3/4 to 1 9/16 in, it provides versatility for various applications. The system features upper roller positioning with ball bearing rollers for smooth operation.For enhanced rigidity, a door straightener/stiffener is recommended. Richelieu’s Cinetto PS40.1 system seamlessly integrates functionality and style, making it a top choice for modern cabinetry solutions.
CINETTO PS40.1 Coplanar Sliding System
Cinetto PS40.1 Coplanar Sliding System for large cabinet doors weighing up to 132 lb (60 kg) each.
Features:
– Flexible system for one, two, or three wood doors
– Recessed mount hardware, adjustable
– Soft-close mechanism included
– No special cabinet fabrication is required
– Two types of track finishes: silver and stainless steel effect anodized aluminum
– Optional B-moved electronic motor system sold separately
This is an ideal solution for closets, pantries, large storage millwork, and wardrobes/armoires in residential and commercial applications.
IMPORTANT: We recommend that you use a door straightener/stiffener to keep the door rigid.
Attributes
Ship via: No UPS – Common Carrier Only
” Optional” Door Width: 1 300 to 1 800 mm
Adjustable: Yes
Application: Wardrobe, Pantry, Cabinet, Storage
Brand: CINETTO
Brand Model: Cinetto PS40
Door Height: 3 000 mm
Door Installation: Top Hung
Door Material: Wood
Door Movement: Coplanar
Door Position: Full Overlay, Inset/Inlay
Door Thickness: Min. 19 mm
Door Thickness Including the Handle: 19 to 55 mm
Door Width: 1 298 to 1 800 mm
Finish: Satin Aluminum
Height Clearance: 131 mm
Length – Overall Dimensions: 17 ft 8 in*
Load Capacity: 99.2 to 220 lb*
Manufacturing Material: Aluminum
Number of Doors: 3
Opening: Towards the left, left, right
Overall Length: 5 400 mm
PS40 Opening: Towards the left, left, right
Product #: WEBKIT1213686
Product number: WEBKIT1213686
Product №: WEBKIT1213686
Roller Position: Upper
Roller Type: Ball Bearing
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84″ or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Close Type: One-Way Operation
Soft- Closing: Yes
Track Finish: Satin Aluminum
Track Length: 5 400 mm
Track Material: Anodized Aluminum
Track Mounting: Recessed – Inside Ceiling
Weight Capacity per Door: 45 to 100 kg
Resources
- Door width “option”
- Door width “option”
- Guide
- Instructions
- Pull Handle Position
