Center Pivot Arm ANCLR by LCN – High-Quality Door Operator Component

Description

LCN 2850-3077CP 628 Center Pivot Arm Assembly Instructions

LCN 2850-3077CP 628 Center Pivot Arm ANCLR is a versatile door operator designed to enhance accessibility and convenience. This ADA-compliant, two-in-one swing door operator allows for automatic door opening for wheelchair users while also permitting manual operation for regular pedestrian traffic. The 2850 Series is ideal for commercial settings, ensuring compliance with ANSI A156.19 standards and meeting UL approvals for fire doors. The operator comes complete with a motor gearbox, control box, arm, bottom pivot, header, and mounting hardware, facilitating straightforward installation. Its standard 72″ header length can be customized from 60″ to 98″ based on your project needs. The adjustable hold-open period of 1 to 32 seconds in both automatic and manual modes offers flexibility for various applications. This product features a matte silver aluminum finish, a grade 1 rating, and is suitable for commercial installation, emphasizing durability and aesthetics. Additionally, with a limited warranty of 2 years, you can trust its reliability in demanding environments. LCN’s 2850 Series Center Pivot Arm is an essential solution for any facility prioritizing accessibility without compromising functionality.

Center Pivot Arm ANCLR

2850 Series Center Pivot Arm, Arm Only, Aluminum Painted Finish

The 2850 Senior Swing by LCN is an ADA Door Operator That is a Two-in-One Swing Door Operator. Senior Swing Operator when Activated, Opens Doors Automatically for Wheelchair Access, yet Allows for Manual Operation for Regular Pedestrian Traffic.

The 2850 Series is an ADA compliant, two-in-one, swing door operator.

LCN’s 2850 Series is a Senior Swing oeprator that when activated, opens doors automatically for wheelchair access, yet allows for manual operation for regular pedestrian traffic. This series is UL approved for fire doors.

• 2850 series operator is shipped with motor gearbox, control box, arm, bottom pivot, header, and mounting hardware. Actuators available separately, see pages 199-215.
• Simultaneous pair, overhead concealed.
• Meets ADA, requirements (power mode only).
• Handed product.
• 72” header length is standard. Specify other length 60” to 98” max. Consult factory regarding this option.
• Fixed or breakaway stop available (center pivot arm).
• Adjustable hold open period of 1 to 32 seconds in automatic or manual mode.

Attributes

Manufacturer surcharge: 4.5%

Accessible: Yes

Ada Compliance: Yes

Ansi: ANSI A156.19

Commercial Residential: Commercial

Cover: Less Cover

Finish: 689

Finish Family: Matte Silver

Grade: Grade 1

Installation: Commercial

Limited Warranty: 2 Years

Pack Qty: 1

Series: 2850 Series Electromechanical Senior Swing Operators

Subtype: Door Operators

Type: Door Closers and Operators

Ul Listing: UL325, UL1998

Unit of Measure: Each

Resources

• 2850 Series Electromechanical Senior Swing Operators Cut Sheet
• Choosing the Right LCN Auto Operator
• LCN 2800 Series Installation Instructions
• LCN 2800 Series Senior Swing Control Box Installation Instructions
• LCN 4840 Series Product Guide – Automatic Operators
• LCN Auto Operators Catalog
• LCN Electromechanical Automatic Operators Data Sheet
• LCN Senior Swing Installation Video
• Von Duprin Finishes Chart
