AVENTOS HS Top – Premium Integrated Vertical Opening System by Richelieu

Description

Richelieu WEBKIT1249733 AVENTOS HS Top Kit – Canada

Richelieu WEBKIT1249733 kits AVENTOS HS top offers a compact and efficient solution for large, single-piece facades, ensuring a smooth and effortless opening mechanism. This innovative system allows doors to tilt gently above the cabinet, providing a weightless sensation and unparalleled freedom of movement, perfect for spaces where functionality and design converge. Designed for cabinets measuring from 350 to 800 mm in height and up to 1,800 mm in width, the AVENTOS HS top accommodates a minimum interior depth of 264 mm. The integrated BLUMOTION damper adjustment feature minimizes resistance forces, allowing for a seamless opening experience. Additionally, its continuous stop and fixed position for the force reservoir enhance usability and stability. Tool-free assembly simplifies installation, while the two types of force reservoir mounting and 3-dimensional face adjustment offer versatility in application. The system opens outside the movement range, ensuring complete access to the interior without encroaching on workspace, maximizing storage capacity without the need for a cross stabilizer. For those working with thin facades, the compatible 20S42T1 front attachment is available among the suggested products, further enhancing design possibilities. Upgrade your cabinetry with the Richelieu AVENTOS HS top for a blend of style and efficiency.

kits AVENTOS HS top -Canad –

A compact and functional solution for large doors

Designed for large, single-piece facades, AVENTOS HS top ensures smooth and effortless opening. The door tilts gently above the cabinet, offering a weightless sensation and unparalleled freedom of movement.

Product highlights:
– Ideal for large single-piece facades
– Cabinet height from 350 to 800 mm (13 3/4 in – 31 1/2 in)
– Cabinet width up to 1,800 mm (70 7/8 in)
– Minimum interior depth of cabinet body: 264 mm (10 3/8 in)
– Integrated BLUMOTION damper adjustment
– Minimal resistance forces
– Continuous stop
– Fixed position for the force reservoir and front attachment
– Symmetrical force reservoirs and arms
– Tool-free assembly
– Two types of force reservoir mounting
– 3-dimensional face adjustment

Thanks to its opening outside of the movement range, access to the interior is complete, without encroaching on workspace. Without a cross stabilizer, it maximizes storage capacity while seamlessly integrating into designs for optimized space and controlled ergonomics.

For thin facades, use the 20S42T1 front attachment, which can be found among the suggested products.

Attributes

Brand: Blum

Door Height: 17 3/4 to 21 1/4 in*

Door Length: Max. 70 7/8 in*

Door Type: Narrow Aluminum-Framed Door (20 mm and Less)

Door Weight: 5.51 to 27.6 lb*

Finish: Dark Gray

Minimum internal depth of the enclosure: Min. 10 3/8 in*

Opening Types: Up and Over Opening

Product #: WEBKIT1249733

Screw/ Nail: Pre-Mounted Euro Screw

Resources

• AVENTOS HS top product sheet
• Brochure
• Installation
• Instructions for BLUMOTION replacement
