Description
Richelieu WEBKIT1248913 AVENTOS HKi Semi-Recessed Set, No Handle
Richelieu WEBKIT1248913 AVENTOS HKi Semi-Recessed Set Without Handle offers a sleek, compact solution for modern cabinetry. Designed with a narrow mechanism and ultra-thin cover, this lift mechanism integrates seamlessly into the cabinet body, enhancing the aesthetic appeal while maximizing functionality.The AVENTOS HKi is ideal for frameless cabinets and supports both wide and narrow aluminum-framed doors, accommodating a door thickness of 5/8 to 31/32 inches and a maximum door weight of 39.7 pounds. One of its standout features is the force reservoir adjustment located at the front, which allows for precise control depending on the weight of the door and cabinet height. The integrated opening angle limiter and continuous stop ensure smooth operation and safety. Equipped with soft-close and touch release motion technology, this system provides a refined user experience, allowing for effortless lift-up openings. The light gray finish adds a subtle elegance to any kitchen or cabinetry design. For optimal performance, it is recommended to conduct a test installation, especially when using additional force reservoirs or when operating near weight limits. The AVENTOS HKi system embodies a perfect blend of style and advanced functionality, making it an excellent choice for discerning homeowners and building professionals alike.
AVENTOS HKi Semi-Recessed Set Without Handle
Compact and Narrow Mechanism, Ultra-Thin Cover
AVENTOS HKi integrates partially into the side of the cabinet body. The lift mechanism fitting thus blends seamlessly into the furniture, opening up new possibilities for high-end aesthetic designs. You achieve a pure piece of furniture and total freedom of arrangement.
Some advantages:
– Force reservoir adjustment at the front
– Integrated opening angle limiter
– Continuous stop
Note:
The power factor allows you to determine the appropriate force reservoir. The power factor depends on the weight of the front (double the weight of the handle included) and the height of the cabinet body. If a third force reservoir is used (increasing the power factor by up to 50%), we recommend a test installation.
For wide cabinet bodies, we recommend attaching an additional force reservoir to an intermediate side panel due to the flexing of the front in the open position. We recommend conducting a test installation when the values for each force reservoir are at the limit of the allowable values!
Attributes
Brand: Blum
Cabinet Model: Frameless
Door Height: Max. 23 5/8 in*
Door Length: Max. 70 7/8 in*
Door Thickness: 5/8 to 31/32 in*
Door Type: Wide Aluminum-Framed Door / Narrow Aluminum-Framed Door (20 mm and Less)
Door Weight: Max. 39.7 lb*
Finish: Light Gray
Motion Technology: Soft-Close, Touch Release
Opening Types: Lift-Up Opening
Power Factor: 1 730 to 5 200
Product #: WEBKIT1248913
