Description
Schlage L9056B OMEA 626 Automatic Unlocking Mortise Lock, IC Core, Omega Lever, Satin Chrome
Schlage Commercial L9056BOMEA626 Automatic Unlocking Entry Mortise Lock combines advanced functionality with elegant design, making it an ideal choice for office and entry applications. This lock features a small format interchangeable core, allowing for easy rekeying and enhanced security. The satin chrome finish not only adds a sleek aesthetic but also ensures durability and resistance to wear. Designed with a 2-3/4″ backset, this mortise lock offers a seamless fit for most standard doors. The 2-1/8″ rose complements a 5-1/16″ lever with a 3-5/16″ projection, providing a comfortable grip and easy operation. The automatic unlocking feature enhances convenience, allowing for effortless access without the need for manual locking or unlocking. Reversible handing ensures versatility in installation, accommodating a variety of door orientations. The ANSI strike provides a reliable framework for secure closure, making this lock a trusted choice for high-traffic environments. As part of the L Series, the Schlage Commercial L9056BOMEA626 is engineered for performance and longevity, meeting the demands of both building professionals and discerning homeowners. With the capability to ship via UPS, this lock is ready to enhance your space efficiently and effectively.
Automatic Unlocking Entry Mortise Lock with Small Format IC Less Core with Omega Lever and A Rose Satin Chrome Finish
Attributes
Ansi: A156.13-2017 Series 1000
Baa Qualified: Yes
Backset: 2-3/4″ Backset
Bolt Projection: 3/4″ Latch
Bolt Protection: 3/4″
Burglar Rated: No
Cam Number: L583-255
Cam Type: Schlage L
Commercial Residential: Commercial
Country of Origin: Mexico
Country of origin: Mexico
Cylinder Length: 1-3/8″
Cylinder Type: SFIC Prep Less Core
Design: NULL
Dimension: 2-1/8″ Rose with 5-1/16″ Lever and 3-5/16″ Projection
Door Thickness: 1-3/4″
Dust Box: Plastic
Finish: Satin Chrome
Finish : Satin Chrome
Finish Family: Matte Silver
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: 9056-Entrance Office w Auto Unlocking
Function Family: Entrance/Office
Grade: Grade 1
Hand: Field Reversible
Handing: Reversible
Installation: Commercial
Latch Backset Dim: 2-3/4″
Latch Type: Dead Latch (Guarded)
Lever Knob Design: OME – Omega
Lever Knob Design Family: Curved Return Lever
Leverknob Design: OME – Omega Lever
Leverknob Design Family: Curved Return Lever
Limited Warranty: 3 Years
Lock Face Size: 8″ x 1-1/4″
Manufacturer Function : Latchbolt retracted by knob/lever from either side unless outside is made inoperative by key outside or by rotating inside thumbturn. Outside knob/lever unlocked by key outside, thumbturn or closing door. Rotating inside knob/lever simultaneously retracts latchbolt and unlocks outside knob/lever. Auxiliary latch deadlocks latchbolt when door is locked. Inside knob/lever is always free for immediate egress.
Num Pins: 6 to 7
Origin: Mexico
Pack Height: 5.63″
Pack Height 2: 5.63″
Pack Length: 10.38″
Pack Length 2: 10.38″
Pack Qty: 1
Pack Volume: 313.68 in³
Pack Volume 2: 313.68 in³
Pack Width: 5.38″
Pack Width 2: 5.38″
Pins: 6 to 7
Pocket Dimensions: 6-5/8″ x 4-1/2″
Projection: 3.313″
Restrictions: None
Rose Escutcheon Design: A – Rose
Rose Escutcheon Dimensions: 2-1/8″
Roseescutcheon Design: A Rose
Roseescutcheon Dimensions: 2-1/8″
Screws: Combination
Series: L Series
Ship Weight: 6.3 lbs.
Std Latch Backset Dim: 2-3/4″
Std Latch Type: Dead Latch (Guarded)
Std Strike Height: 4-7/8″
Std Strike Number: 10-072 1316 626
Std Strike Type: ANSI Strike
Std Strike Width: 1-3/16″
Strike: ANSI Strike
Strike Height: 4-7/8″
Strike Number: 10-072
Strike Type: ASA
Strike Width: 1-1/4″
Subtype: Mortise Lock
Type: Locks, Cylinders, Cores, Keyblanks
Ul Listing: UL Listed
Unit of Measure: Each
Unit of Measure 2: Case
Unit of Measure 2 Qty: 6
