Arrow Mortise Lock – Secure and Reliable Apartment Locking Solution

Description

Arrow Lock BM11 JL 10B Apartment Mortise Lock

Arrow Lock BM11 JL 10B Mortise Lock is a robust solution designed specifically for apartment and front door applications. This lock features a J lever and L rose design in an elegant oil-rubbed bronze finish, adding both style and security to your entryway. Engineered with heavy-duty use in mind, it meets the demands of commercial, institutional, and industrial environments, including schools and hospitals. Constructed from heavy gauge steel with a zinc dichromate finish, this lock ensures excellent corrosion resistance and long-lasting durability. The lock case is field reversible, allowing for easy re-handing without disassembly. It accommodates standard door thicknesses of 1-3/4″ and features a 2-3/4″ backset for compatibility with various door types. The lock includes a stainless steel latchbolt with anti-friction insert, a one-piece stainless steel deadbolt, and an armored front that fits flat and beveled doors. With a five-year limited warranty, this Grade 1 mortise lock provides peace of mind and reliability. Keying options include master keying, construction master keying, and high-security cylinders, catering to diverse security needs. Enhance your property’s security with the Arrow Lock BM11 JL 10B, where performance meets precision.

Mortise Lock – Apartment

Apartment, Front Door Mortise Lock, J Lever, L Rose, Oil Rubbed Bronze

Arrow mortise locks are offered in a complete range of functions designed for commercial, institutional and industrial applications. They are engineered for strength and performance, and precisely manufactured to exacting standards. Arrow mortise locks are intended for heavy duty use in schools, hospitals and commercial buildings where security, durability and low maintenance are required. The lock case is made from heavy gauge steel, with zinc dichromate finish for corrosion resistance and it can be re-handed without disassembling the lock case. A wide selection of trim designs and functions are offered which meet or exceed the performance requirements of ANSI Grade 1.

The BM Series are engineered for strength and performance, and precisely manufactured to exact standards.

Arrow BM Series Lever Mortise Locks are intended for heavy duty use in schools, hospitals and commercial buildings where security, durability and low maintenance are required.

• Handing:Handed; field reversible. The lockset can be re-handed without disassembling the lock case.
• Door Thickness:1-3/4″ (4mm) standard. Optional door thickness available; consult factory.
• Backset:2-3/4″ (70mm).
• Lockcase:Heavy gauge steel, with zinc dichromate finish for corrosion resistance. 5-7/8″ (149mm) x 4″ (102mm) x 15/16″ (24mm).
• Armored Front:Heavy gauge steel, 8″ (203 mm) x 1-1/4″ (32mm) x 3/32″ (2mm). Accommodates flat doors and doors beveled 1/8″ (3mm) in 2″ (51mm).
• Faceplate:Wrought brass or bronze, attached by machine screws to lockcase front.
• Latchbolt:Stainless steel, 2 piece mechanical with anti-friction insert. 5/8″ (16mm) x 1″ (25mm) x 3/4″ (19mm) throw.
• Auxiliary Latchbolt:9/16″ (14mm) effective throw and 3/8″ (10mm) effective auxiliary latch deadlocking.
• Deadbolt:One-piece stainless steel, 19/32″ (15mm) x 1 1/4″ (32mm) x 1″ (25mm) throw.
• Hub:Lever: nickel steel, 5/16″ (8mm).
• Spacing:Center to center, hub to cylinder: 3-5/8″ (92mm).
• Center to center, hub to turnpiece: 2-7/16″ (62 mm).
• Strike:Wrought brass or bronze, ANSI straight lip standard, 4-7/8″ (124mm) x 1-1/4″ (32mm) 1-1/8″ (29mm) lip to center. Optional strikes, lip lengths and ANSI wrought strike box available.
• Keys:Two nickel silver standard.
• Keying Features Available:
  • Master keying
  • Construction master keying
  • Visual key control
  • Concealed key control
  • High security cylinder
  • Interchangeable core (IC) – Pointe, Pointe Flex
• Warranty:Five-year limited.

Attributes

Ansi Function: F12 – Entry Office

Application: Complete Lock

Base Material: Bronze

Bolt Projection: 3/4″

Cylinder Type: Conventional Cylinder

Door Thickness: 1-3/4″

Finish: 613/US10B

Fire Rated: 3 Hours {A}

Fire Rating: 3 Hours {A}

Function: 11-Apartment/Front Door

Grade: Grade 1

Handing: Field Reversible

Keying: Keyed Different

Keys: Cut

Leverknob Design: J – Lever

Limited Warranty: 5 Years

Lock Face Size: 8″ x 1-1/4″

Of Keys: 2

Pack Height: 4.5″

Pack Length: 9.25″

Pack Qty: 1

Pack Volume: 239.34 in³

Pack Width: 5.75″

Pins: 6

Product Height: 8″

Product Length: 2.88″

Product Width: 2.25″

Roseescutcheon Design: L – Rose

Screws: Combination

Series: BM Series Mortise Locks

Ship Weight: 6 lbs.

Std Keyway: A

Std Strike Height: 4-7/8″

Std Strike Number: 460

Std Strike Type: ASA

Std Strike Width: 1-1/4″

Subtype: Mortise Lock

Type: Locks, Cylinders, Cores, Keyblanks

Unit of Measure: Each
