Description
Special unique carbide for longer lifetime in abrasive material. Designed for CNC applications requiring high feed rates and a clean finish.
*Oriented strand board is an engineered wood particle board.
| Manufacturer | Amana Tool Corp. |
|---|---|
| Condition | New |
| Application | Laminate, Laminated Plywood, Melamine, Melamine Particle Board, MDF/HDF, Oriented Strand Board (OSB)*, Particle Board, Softwood/Hardwood, Veneered Plywood |
|---|---|
| Type | Router Bit |
| Material | Solid Carbide |
| Flute Type | Compression Spiral |
| Feed Rate IPM* / Chip Load Per Tooth / Ramp Down (Wood/Plywood/Plastic) | 280″ / 0.0077″ / 140″ |
| Feed Rate IPM* / Chip Load Per Tooth / Ramp Down (MDF/Laminate) | 400″ / 0.0111″ / 200″ |
| Flutes | 2 |
| Diameter (D) | 1/2″ |
| Cutting Height (B) | 1 1/4″ |
| Cutting Height (B1) | 11 mm |
| Shank Diameter (d) | 1/2″ |
| Overall Length (L) | 3″ |
| Package Size | 5 Piece |
