ALX Series Storeroom Function Kit – Schlage Commercial – Aged Bronze Finish

Description

Schlage ALX FK 80 643e 234 ALX Storeroom Function Kit, 2-3/4″ Backset, Aged Bronze Finish

Schlage Commercial ALXFK80643E234 ALX Series Storeroom Function Kit combines durability with security, making it an ideal choice for commercial applications. Designed for 1-3/8″ to 1-3/4″ thick doors, this mechanical lockset features a 2-3/4″ backset latch that ensures a secure fit. The storeroom function allows for controlled access, perfect for areas requiring restricted entry. The aged bronze finish adds a touch of elegance while providing resilience against wear and tear. Crafted from steel and zinc dichromated materials, the lockset is built to withstand the rigors of daily use. Additionally, the reversible handing enables easy installation on either side of the door, accommodating various configurations. With a latch faceplate dimension of 1-1/8″ x 2-1/4″, the ALX Series lockset is designed for seamless integration into your existing door hardware. It is also UL listed for 3-hour fire doors, ensuring compliance with safety standards. Backed by a 10-year limited warranty, the Schlage Commercial ALXFK80643E234 offers peace of mind with its reliable performance. Whether for new construction or renovations, this storeroom function kit is an excellent addition to any professional setting.

ALX Series Storeroom Function Kit with 2-3/4″ Backset Latch Aged Bronze Finish

Attributes

Accessible: Yes

Ada Compliance: Yes

Alternate Codes: ALX FK 80 643E 234, ALXFK80643E234

Ansi: A156.2-2011 Series 4000, Grade 2

Ansi Function: F86 – Storeroom

Backset: 2-3/4″ Backset

Base Series: ALX Series

Category: Mechanical Commercial Locksets

Commercial Residential: Commercial

Country of Origin: Mexico

Country of origin: Mexico

Door Range: 1-3/8″ to 1-3/4″

Door Thickness: 1-3/8″ – 1-3/4″

Finish: Aged Bronze

Finish Code: 643E

Finish Color: Aged Bronze, Venetian Bronze

Finish : Aged Bronze

Finish Family: Dark Bronze

Fire Rated: 3 Hours {A}

Fire Rating: 3 Hours {A}

For Use With: Schlage ALX Series Levers

Function: 80-Storeroom Lock

Function Family: Storeroom

Grade: Grade 2

Handing: Reversible

Hazardous Material: NO

Installation: Commercial

Latch Backset Dim: 2-3/4 In.

Latch Faceplate Dimension: 1-1/8″ x 2-1/4″

Latch Number: 47267042

Latch Type: Dead Latch (Guarded)

Limited Warranty: 10 Years

Manufacturer Function: Storeroom Lock

Manufacturer Warranty: 10 Year Limited Warranty

Material: Steel, Zinc Dichromated

No Of Inners: 1

Order_ Qty: 1

Origin: Mexico

Pack Qty: 1

Series: ALX Series

Std Latch Backset Dim: 2-3/4″

Std Latch Number: 47267042

Std Latch Type: Dead Latch (Guarded)

Subcategory: Commercial Parts

Subtype: Lock Parts

Type: Locks, Cylinders, Cores, Keyblanks

Ul Listing: UL/cUL

Ul Listing Type: UL Listed for 3 Hour Fire Door

Unit of Measure: Each

Resources

• ALX Configure Chart
• ALX Cylinders and Keyways Reference Guide
• ALX Key Systems, Cylinders and Keys Catalog
• ALX Series Cut Sheet
• ALX Series Lever Locks Cut Sheet
• ALX Series Product Catalog
• ALX Series Service Manual
• Schlage ALX Series Installation Instructions
• Schlage ALX Series Sell Sheet
• Von Duprin Finishes Chart
