Description
Aiphone GT-MKB-N Video Guard Station
Aiphone GT-MKB-N Video Guard Station combines advanced security features with user-friendly functionality, making it an ideal choice for multi-tenant environments. This versatile guard station supports up to 500 tenant stations and is designed with ADA compliance in mind, ensuring accessibility for all users. The unit features a 170° PanTilt & Zoom video camera, providing an expansive viewing area to monitor entrances effectively. Equipped with a built-in access code keypad, the GT-MKB-N enhances security while offering convenient entry options. Communication is facilitated through hands-free, voice-actuated methods or push-to-talk functionality, ensuring seamless interaction with visitors. The station also includes three distinct call tones, enhancing user awareness in various situations. Installation is straightforward, requiring 24V DC power-ideal for commercial settings. The wiring specifications call for two-conductor cables, suitable for both audio and video transmission. The compact design features a 3.5-inch display, making it easy to install in various locations without compromising on functionality. With a shipping weight of 3.2 lbs and an efficient packing volume of 316.2 in³, the Aiphone GT-MKB-N is not only a robust solution for security but also practical for installation and use in commercial applications.
VIDEO GUARD STATION
Video Guard Station, With NFC Reader
Supports up to 500 tenant stations.
ADA compliant design that provides buildings with a mix of all stations. Has a170° PanTilt & Zoom video camera for larger viewing area and built-in access code keypad.
- Power Supply:24V DC – Use PS-2420UL (for GT-BC, GT-VBC, GT-NS, GT-MK, GT-BCX, and GT-2C)
- Current Consumption:GT-BC: 0.9 A, GT-VBC: 0.9 A, GT-NS: 0.13 A, GT-MK: 0.18 A, GT-BCX: 0.35 A,
- GT-2C: 0.26 A, GT-2H: 0.11 A
- Call Tone:There are three different types of call tones: from entrance station, security guard station, and doorbell
- Talk & Video Path:Secure single channel
- Communication:Hands-free, voice-actuated communication or push-to-talk communication
- Door Release:Connecting terminals: between ELM – ELC (N/O) and ELB – ELC (N/C) Specifications: less than 4A (resistance load), 24V AC/DC, dry closure contact
- Wiring:Two conductor cables (Aiphone #872002 for audio and Aiphone #871802 for video)
- Type of Cables:Pair cable (solid wire – not stranded), polyethylene insulated, low cap, diameter 20AWG-18AWG
Attributes
Commercial Residential: Commercial
Communication: Voice and Video
Country of origin: Thailand
Display Size: 3.5 Inch
Installation: Commercial
Operating Voltage: 24 VDC
Origin: Thailand
Pack Height: 3.4″
Pack Length: 9.3″
Pack Qty: 1
Pack Volume: 316.2 in³
Pack Width: 10″
Series: GT Multi-Tenant Color Video Entry Security System
Ship Weight: 3.2 lbs.
Station Type: Speaker
Subtype: Intercoms
Type: Intercoms
Unit of Measure: Each
Wire Required: 2-Conductor, Pe Insulation, Common Bus Aiphone #872002, 2-Cond. Pe Insulated, Non-Shielded, 20AWG
