Adams Rite Flush Lockset With Cylinder – Secure Your Doors

Description

Adams Rite 4190-10-02-119-01-IB Flush Lockset with Cylinder

Adams Rite 4190-10-02-119-01-IB Flush Lockset With Cylinder is designed for sliding doors, offering a sleek and unobtrusive locking solution. This lockset features a square lock face and is compatible with stile thicknesses ranging from 1-7/16″ to 1-5/8″. Its unique design projects only 1/10″ from the door stile on either side, allowing doors to glide effortlessly past other sliding units or stationary panels without the risk of snagging draperies or hindering stacking in wall pockets. The 4190 model incorporates a flush-mounted cylinder on the exterior, while the interior operation is simplified with a convenient slide button set flush in a deeply recessed finger pull. This functionality is built on the reliable Adams Rite MS1847 mechanism, known for its durability and effectiveness. It features an adjustable, self-protecting bolt, ensuring robust security. This lockset is specifically tailored for commercial use and is not recommended for wood doors. For those seeking a cohesive look, a matching dummy set (model 4195) is available. With its combination of practicality and style, the Adams Rite 4190 Flush Lockset is an excellent choice for enhancing the functionality and security of sliding door systems.

Flush Lockset With Cylinder

Flush Lockset with Cylinder, Square Lock Face, 1-7/16″ to 1-5/8″ Stile Thickness, Black

The 4189 and 4190 Flush Locksets for sliding doors combine the time-tested and field-proven Adams Rite MS1847 with a slide button. Projecting only 1/10″ from the door stile on either side, 4189 and 4190 locksets allow doors to slide freely past other sliding units or stationary panels. There are no projecting handles to tear draperies or prevent the door from being “stacked” in a wall packet. 4190 has a flush mounted cylinder outside. Not recommended for wood doors. Both locksets operated from inside by a simple up or down movement of a slide button, set flush in the deeply recessed finger pull. The lock mechanism (latching action unavailable) is the time-tested and field-proven Adams Rite MS1847 and features the adjustable, self-protecting bolt. Matching “dummy set” is also available (4195).

Adams Rite makes a great selection of deadlocks and flush locksets.

Attributes

Commercial Residential: Commercial

Finish: 119

Installation: Commercial

Pack Qty: 1

Pbs Options: 10391043,10401734,10401740

Series: Flush Locksets and Deadlocks

Subtype: Flush Locksets

Type: Locks, Cylinders, Cores, Keyblanks

Unit of Measure: Each

Resources

• 1875 Two Point Deadlock Installation Instructions
• 4189, 4190 Flush Locksets Installation Instructions
• 4430, 4431 Flush Locksets Installation Instructions
• Flush Locksets and Deadlocks Cut Sheet
