Adams Rite 7103A-410 16VDC Electric Strike
Adams Rite 7103A-410 Electric Strike 16VDC is a Grade 1 electric strike designed for fail secure applications, providing robust security and convenience. This model operates on 16VDC and is engineered for remote electrical control, making it compatible with Adams Rite 4500, 4700 (discontinued), and 4900 deadlatches or cylindrical locksets featuring a latchbolt projection of 1/2″ [12.7 mm] to 5/8″ [15.9 mm].The electrical actuation mechanism unlocks the keeper, allowing the door to be opened effortlessly without direct manipulation of the latch. Ideal for aluminum, hollow metal, or wood doors, the strike’s case dimensions measure approximately 1″ x 3-3/8″ x 1-5/8″ deep. It features a stainless steel bolt retainer jaw and a strike opening of 5/8″ x 1-7/16″ x 1/2″ deep, ensuring durability and reliability. Field convertible from fail-safe to fail-secure mode, the 7103A-410 electric strike is suitable for commercial installation and adheres to ANSI/BHMA A156.23 standards. With a holding force of 1500 lbs static and 70 ft lbs dynamic, this unit is built to withstand heavy use. Backed by a 5-year limited warranty, it is a dependable choice for enhancing door security in any facility.
Electric Strike 16VDC
Grade 1 Electric Strike, Fail Secure, 16VDC, Less Faceplate
Remote Electrical Control of Any Door Equipped with an Adams Rite 4500, 4700 (Discontinued), or 4900 Deadlatch or Cylindrical Lockset with 1/2″ [12.7 mm] To 5/8″[15.9 mm] Latchbolt Projection. Electrical Actuation Unlocks the Keeper, Releasing the Latchbolt so the Door May Be Opened Without Operating the Latch Itself.
Designed for use with Adams Rite deadlatches or cylindrical locksets with 1/2″ to 5/8″ latchbolt projection.
For use in aluminum, hollow metal, or wood applications — remote electrical control of any door equipped with an Adams Rite 4500, 4700 (discontinued), or 4900 Deadlatch or cylindrical lockset with 1/2″ [12.7 mm] to 5/8″ [15.9 mm] latchbolt projection. Electrical actuation unlocks the keeper, releasing the latchbolt so the door may be opened without operating the latch itself.
- Fail-Safe/Fail-Secure: Field convertible from one mode to the other. However, AC intermittent solenoid must not be used continuously in either.
- Case: Approximately 1” x 3-3/8” x 1-5/8” deep.
- Strike Lip: Basic 7100 strike has lip of proper length for 1-3/4” thick door that closes flush with jamb edge. Where door thickness or jamb shape differs from this standard relationship, lip extension kits are available, specified by last dash number. Not available on 7101.
- Strike Opening: 5/8” x 1-7/16” x 1/2” deep. Bolt retainer jaw is stainless steel. Strike accepts bolt of any Adams Rite 4500, 4700 (discontinued), or 4900 Deadlatch or cylindrical latches.
- Faceplate: Measures 1-1/4” x 4-7/8”. 7100 has flat faceplate; 7101 is radiused to match nose on inactive leaf in a pair of narrow stile glass doors. Available in a wide range of architectural finishes.
- Voltage: Available in 12 or 24 volt AC and DC. DC continuous units are silent, AC intermittent units “buzz” on operation.
Attributes
Amp Draw: .22 Amps
Ansi: ANSI/BHMA A156.23
Commercial Residential: Commercial
Function: Fail Secure
Grade: Grade 1
Holding Force: 1500 lbs Static, 70 ft lbs Dynamic
Installation: Commercial
Limited Warranty: 5 Years
Operating Voltage: 16VDC
Pack Qty: 1
Pbs Options: 1,039,639,610,396,400,000,000,000
Series: 7100 Electric Strikes
Subtype: Electric Strikes
Type: Electric Strikes, Bolts, Magnets
Ul Listing: UL 1034 and UL 294 Listed
Unit of Measure: Each
