Description
NGP 700U 72″ Mill Aluminum Polyurethane Perimeter Seal
NGP 700U 72″ Mill Aluminum Polyurethane Perimeter Seal offers an exceptional solution for maintaining the integrity of your commercial restroom partitions. Constructed from durable aluminum alloy 6063 with a T5 temper, this seal provides outstanding abrasion resistance, tensile strength, and UV stability. Designed to withstand extreme temperatures ranging from -80°F to 200°F, it is both flame and moisture resistant, ensuring longevity and reliability in various environments. The NGP 700U features a unique design that allows for closer mounting without breaking the seal, making installation straightforward. The head section is not pre-drilled, while the jamb sections come with slotted holes, enabling easy adjustments. Additionally, this seal facilitates the mounting of rim exit device strikes without the need for notching gasketing, enhancing its versatility. Included with the product are self-drilling #8 (Tek type) screws for a hassle-free installation. The polyurethane material is presented in a sleek black finish, seamlessly complementing any modern restroom design. For custom fitting, the seal may be cut to width upon order specification. With certifications for fire resistance and air infiltration, the NGP 700U ensures safety and efficiency in your building’s restroom facilities.
72″ Mill Aluminum Polyurethane Perimeter Seal
- Allows mounting of rim exit device strikes without notching gasketing
- Self drilling #8 (Tek type) screws furnished
- Flame resistant
- Jamb sections furnished with slotted holes for adjustment
- Polyurethane is black
- No break in seal for closer mounting
- May be cut to fit narrow frame stops
- Mill aluminum
- Temperature range -80°F to 200°F
- Specify “cut to width” on order
- Head section not drilled
- Moisture resistant
- Closer and/or overhead holder attach to frame through weatherseal section. Install seal first
- Aluminum alloy 6063, T5 temper
- Very good abrasion resistance, tensile strength, memory and UV resistance
Attributes
Color: Polyurethane is black
Dimensions: Specify “cut to width” on order
Fasteners: Self drilling #8 (Tek type) screws furnished
Fire Rated: Flame resistant
Length: 72.0″
Material: Mill aluminum
Moisture Resistant: YES
Resistance: Very good abrasion resistance, tensile strength, memory and UV resistance
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 96″ or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Standard-0: CERTIFIED by UL to CAN/ULC-S104 and ANSI/UL10B, complies with NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-1: POSITIVE PRESSURE – CERTIFIED by UL to ANSI/UL10C, complies with IBC, NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-2: AIR INFILTRATION TESTED to ASTM E283, Standard Test Method for Determining Rate of Air Leakage Through Exterior Windows, Curtain Walls, and Doors.
Temperature Range: Temperature range -80°F to 200°F
