6-Pin LFIC Mortise Housing by Corbin Russwin

Description

Corbin Russwin 1070-112-A01-6 622 6-Pin LFIC Mortise Housing

Corbin Russwin 1070-112-A01-6 622 6-Pin LFIC Mortise Housing offers a durable and efficient locking solution for commercial applications. Designed with a 1-1/2″ cylinder length, this mortise housing features a robust A01 Cloverleaf Cam and is finished in an elegant flat black tone (622/US19). Crafted from solid brass, it is built to accommodate Corbin Russwin 8000 Series Interchangeable Cores in both 6-pin and 7-pin configurations, enhancing its versatility across varied keying systems. The interchangeable core design allows for quick rekeying without the need to remove the hardware from the door, making it an ideal choice for office buildings, hotels, schools, hospitals, and universities. This convenience translates into significant time and cost savings over the lifespan of any building. All operating keys function normally, while a unique control key facilitates core removal and installation at a separate shear line. Additionally, the Corbin Russwin 1070-112 provides options for construction keying and concealed key control (CKC) for heightened security. With a limited one-year warranty, this mortise housing is a reliable choice for professionals seeking efficient lock solutions.

6-Pin LFIC Mortise Housing

1-1/2″ 6-Pin Mortise Housing, A01 Cloverleaf Cam, Flat Black Finish

Corbin Russwin Interchangeable Core Mortise and Rim Housings are made from soldi brass and are available to accept Corbin Russwin 8000 Series Interchangeable Cores in 6 or 7-Pin versions.

Interchangeable cores provide rekeying convenience for virtually all types of keying systems.

Interchangeable cores like thissavetime and money over the life of a building.

• Advantages

Rekeying can be done by non-technical personnel without removing hardware from the door. When used system wide, IC provides tremendous rekeying convenience. When planned from the inception of a system, IC cylinders can be integrated with conventional cylinders.

• Applications

IC is recommended for virtually all types of keying systems, such as office buildings, hotels, schools, hospitals and universities. When used in exit devices and other installations which are labor intensive to rekey, IC saves time and money over the life of the building.

• Operations

All operating keys (change, master, grand master) operate the lock normally. To rekey, use the special control key. The control key operates at a separate shear line in certain chambers within the core. Only the control key is required to remove and install a core.

• Cores

Cores are available in 6-pin (standard), 7-pin, security and Pyramid.

• Construction Keying

Corbin Russwin recommends temporary construction cores for greater security. Special construction master keying is also available, when planned from the inception of the keying system.

• Core Marking

Concealed Key Control (CKC) is available for all Corbin Russwin cores.

Attributes

Baa Qualified: Yes

Cam Number: A01

Cam Type: Corbin Russwin Clover

Commercial Residential: Commercial

Country of origin: USA

Cylinder Length: 1-1/2″

Cylinder Type: Corbin Russwin 6-Pin LFIC Mortise Housing

Finish: 622/US19

Finish Family: Black

Installation: Commercial

Limited Warranty: 1 Year

Origin: USA

Pack Height: 2.5″

Pack Height 2: 6″

Pack Length: 4″

Pack Length 2: 16.25″

Pack Qty: 1

Pack Volume: 27.5 in³

Pack Volume 2: 1023.75 in³

Pack Width: 2.75″

Pack Width 2: 10.5″

Pins: 6

Series: Interchangeable Core Cylinders

Ship Weight: 0.4 lbs.

Subtype: LFIC Mortise Housing

Type: Locks, Cylinders, Cores, Keyblanks

Unit of Measure: Each

Unit of Measure 2: Case

Unit of Measure 2 Qty: 32
