48″ Anodized Aluminum Nylon Brush Seal – NGP Weatherstripping

Description

NGP H612A-48 National Guard Products Weatherstrip

Certifications

	CERTIFIED by UL to CAN/ULC-S104 and ANSI/UL10B, complies with NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
	POSITIVE PRESSURE – CERTIFIED by UL to ANSI/UL10C, complies with IBC, NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
	SMOKE & DRAFT CONTROL GASKETING. Door Sweep Application only. Certified by UL to ANSI/UL10C and ANSI/UL1784 Category ‘H’; complies with IBC and NFPA 105 for use on ‘S’ labeled Positive Pressure Hollow Metal fire doors rated up to 3 hours, and Wood fire doors rated up to 90 minutes.

• Aluminum alloy 6063, T5 temper
• Synthetic polymer: Polyamide
• Excellent abrasion resistance, flexibility and memory
• Moisture resistant
• Retains insecticides well
• Temperature range -70°F to 425°F
• Door Sweep application is Category H Smoke & Draft Control
• REACH and RoHS compliant
• Not effective against water penetration
• #6 x 3/4″ stainless steel sheet metal screws furnished
• Screw holes slotted for adjustment
• Nylon brush is gray
• Anodized aluminum
• FATT – Fast Attach Tape

Attributes

Restriction message: Due to the fragile nature of this item, it can be easily damaged in shipping. The following charges apply to insure your items arrive in good condition. 1 to 12 Pieces: $19.50 13 to 24 Pieces: $39.50 25 to 36 Pieces: $58.50

Application: Door Sweep application is Category H Smoke & Draft Control

Color: Nylon brush is gray

Commercial Residential: Commercial

Fasteners: #6 x 3/4″ stainless steel sheet metal screws furnished

Finish: Anodized aluminum

Finish : Satin Aluminum Clear Anodized

Finish Family: Matte Silver

Fire Rated: 3 Hours

Fire Rating: 3 Hours

Flange Material: Anodized Aluminum

Hardware: #6 x 3/4″ Stainless Steel Sheet Metal Screws

Insert Color: Gray

Insert Material: nylon brush

Installation: Commercial

Length: 48.0″

Material: Synthetic polymer: Polyamide

Moisture Resistant: YES

Pack Qty: 1

Resistance: Excellent abrasion resistance, flexibility and memory

Restrictions: Fragile

Ro HS: REACH and RoHS compliant

Series: NGP Gasketing

Standard-0: CERTIFIED by UL to CAN/ULC-S104 and ANSI/UL10B, complies with NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.

Standard-1: POSITIVE PRESSURE – CERTIFIED by UL to ANSI/UL10C, complies with IBC, NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.

Standard-2: SMOKE & DRAFT CONTROL GASKETING. Door Sweep Application only. Certified by UL to ANSI/UL10C and ANSI/UL1784 Category ‘H’; complies with IBC and NFPA 105 for use on ‘S’ labeled Positive Pressure Hollow Metal fire doors rated up to 3 hours, and Wood fire doors rated up to 90 minutes.

Standards: ANSI/UL10C Category J

Subtype: Weatherstrip

Temperature Range: Temperature range -70°F to 425°F

Type: Nylon Brush Seal

Ul Listing: UL10C

Unit of Measure: Each
