Description
SDC 634RF MR 4A Power Supply Unit
SDC 634RF MR 4 Amp Power Supply is engineered to provide reliable power for electric locks and access control systems. This versatile unit operates at 12/24 VDC and features field-selectable output options, allowing for a single 4 Amp output or two 2 Amp Class 2 outputs. Designed with safety in mind, it includes a cover-mounted manual reset switch for fire and emergency release, ensuring compliance and quick access during critical situations. The robust 4 Amp circuitry is suitable for both inductive loads and multi-door applications, making it an ideal choice for commercial environments. The modular design accommodates a variety of application control modules, delivering customized solutions tailored to your specific security needs. Whether you are managing locking devices, access controls, or remote control systems, this power supply simplifies installation and enhances overall system performance. With dimensions of 16 inches wide, 14 inches high, and 6.5 inches deep, the SDC 634RF is compact yet powerful, making it easy to integrate into existing setups. Documentation is included to facilitate organized installation for individual or multi-door systems. Trust the SDC 634RF for dependable power delivery in your security infrastructure.
4 Amp Power Supply
4 Amp Power Supply, 12/24 VDC Field Selectable, Field Select One 4 Amp Output, or Two 2 Amp Class 2 Outputs, Cover Mounted Manual Reset Switch for Fire/Emergency Release, with 16 In. Wide by 14 In. high by 6.5 In. Deep Box
The SDC 634RF Power Supplies have been developed specifically to support electric locks and access controls. The high performance, heavy-duty 4 Amp circuitry is ideal for inductive loads and multi-door applications. The modular design is built around several different application control modules to meet your specific needs for virtually any electric lock system. Documentation is provided to ensure a well organized installation for individual or multi-door systems that may include locking devices, access controls, station controls and consoles for remote control, annunciation and auxiliary emergency release interface.
Power Supplies have been developed specifically to support electric locks and access controls.
Attributes
Commercial Residential: Commercial
Installation: Commercial
Pack Qty: 1
Series: SDC Power Supplies
Subtype: Power Supplies
Transformer Output: Up to 5 Amps
Type: Power Supplies and Transformers
Unit of Measure: Each
Resources
- 12VR Data Sheet
- 12VR Regulator Module Installation Instructions
- 602RF Data Sheet
- 602RF Power Supply Installation Instructions
- 621 Series AMP Power Supply Installation Instructions
- 621RF data Sheet
- 631RF Data Sheet
- 631RF Power Supply Installation Instructions
- 632RF Data Sheet
- 632RF Power Supply Installation Instructions
- 634RF 4 Amp Power Supply Installation Instructions
- 634RF data Sheet
- 636RF 6 Amp Power Supply Installation Instructions
- 636RF Data Sheet
- Power Supply Chart
- SDC Power Supplies Cut Sheet
