Description
NGP 127SDKB 36 National Guard Products Weatherstrip
PERIMETR SEAL-SILICONE,36″ 3 FOOT, DARK BRONZE
- Flame-Resistant
- Aluminum Alloy 6063, T5 Temper
- Moisture-Resistant
- Synthetic Rubber Polymer: Siloxane Closed Cell Sponge
- Temperature Range -100°F to 500°F, Remains Flexible at Extreme Temperatures
- Dark Bronze Finish
- Excellent Flexibility and Memory
- Silicone is Black
- BHMA Certified to ANSI/BHMA A156.22 Performance Tests for Heat and Cold
- Excellent Resistance to Ozone, UV and Aging
- #6 x 3/4″ Stainless Steel Sheet Metal Screws Furnished
- Recommended for Areas Using FM200 or Halon Fire Suppression Systems
- Screw Holes Slotted for Adjustment
- Patent Pending Microcellular Silicone
Attributes
Application: Excellent Flexibility and Memory
BHMA: BHMA Certified to ANSI/BHMA A156.22 Performance Tests for Heat and Cold
Color: Silicone is Black
Fasteners: #6 x 3/4″ Stainless Steel Sheet Metal Screws Furnished
Finish: Dark Bronze Finish
Finish : Dark Bronze
Fire Rated: Recommended for Areas Using FM200 or Halon Fire Suppression Systems
Length: 36.0″
Material: Synthetic Rubber Polymer: Siloxane Closed Cell Sponge
Moisture Resistant: YES
Patented: Patent Pending Microcellular Silicone
Resistance: Excellent Resistance to Ozone, UV and Aging
Series: NGP Gasketing
Standard-0: CERTIFIED by UL to CAN/ULC-S104 and ANSI/UL10B, complies with NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-1: POSITIVE PRESSURE – CERTIFIED by UL to ANSI/UL10C, complies with IBC, NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-2: AIR INFILTRATION TESTED to ASTM E283, Standard Test Method for Determining Rate of Air Leakage Through Exterior Windows, Curtain Walls, and Doors.
Standard-3: SMOKE & DRAFT CONTROL GASKETING. Certified by UL to ANSI/UL10C and ANSI/UL1784 Category ‘H’; complies with IBC and NFPA 105 for use on ‘S’ labeled Positive Pressure Hollow Metal fire doors rated up to 3 hours, and Wood fire doors rated up to 90 minutes.
Standard-4: ANSI/BHMA CERTIFIED. Certified Gasketing complies with American National Standard for Door Gasketing and Edge Sealing Systems ANSI/BHMA A156.22 and is listed in the BHMA Certified Products Directory.
Subtype: Weatherstrip
Temperature Range: Temperature Range -100°F to 500°F, Remains Flexible at Extreme Temperatures
Type: Hinges and Pivots
