Description
Folger Adam 310-2 3/4 24D 606 300 Series Electric Strike
Folger Adam 310-2 3/4 24D 606 300 Series Electric Strike offers a robust and reliable solution for high-demand environments requiring security and durability. This fail-secure electric strike is crafted from high-quality stainless steel, ensuring exceptional strength and resistance to corrosion, making it ideal for heavy-duty applications. With a fire rating of three hours, it meets UL 10C standards for both single and double doors, providing peace of mind in fire safety compliance. Designed for use with cylindrical locks, mortise exit, and latch locks, the 310 Series features a 3/4″ keeper with a horizontal adjustment capability to accommodate door and frame misalignment. Its impressive static strength of 1,500 lbs. and dynamic strength of 70 ft-lbs. guarantee long-lasting performance, supported by an endurance rating of 500,000 cycles. The electric strike operates at 24VDC and draws .25 amps for continuous duty, making it efficient for commercial applications. With a tamper-resistant design and a five-year limited warranty, the Folger Adam 310-2 ensures reliability and security for any facility. Whether installed in metal or wood frames, this electric strike is New York City accepted and RoHS compliant, making it a superior choice for discerning building professionals and knowledgeable homeowners alike.
300 Series Electric Strike
Fail Secure, Complete 24VDC Electric Strike, 3/4″ Keeper, Satin Brass
The 310 Series is a 3 hour fire-rated, industrial grade electric strike designed for extreme heavy duty applications. The all stainless steel construction of this device makes it ideal for high abuse applications that would disable other electric strikes.
The 310 Series is a 3 hour fire-rated, industrial grade electric strike designed for extreme heavy duty applications.
The all stainless steel construction of this device makes it ideal for high abuse applications that would disable other electric strikes.
- UL 10C fire-rated, 3 hour single door(fail secure only)
- UL 10C fire-rated, 3 hour double door(fail secure only)
- CAN4-S104 (ULC-S104) fire door conformant
- UL1034, burglary-resistant listed
- UL 294 (6th Edition) listed
- ANSI/BHMA A156.31, Grade 1
- New York City accepted
- NFPA-252 fire door conformant
- ASTM-E152 fire door conformant
- RoHS compliant
- .51 Amps @ 12VDC continuous duty
- .25 Amps @ 24VDC continuous duty
- Tamper resistant, heavy-duty construction
- Constructed entirely of stainless steel for strength and corrosion resistance
- Static strength 1,500 lbs.
- Dynamic strength 70 ft-lbs.
- Endurance rating 500,000 cycles
- Horizontally adjustable keeper to allow for door and frame misalignment
- 1/2″ keeper depth (310-2)
- Non-handed
- Fail Secure (standard)
- Plug-in connector
- Five year limited warranty
- Fail Safe
- LCBMA – Latchbolt & Locking Cam Monitor with Auxiliary Switch (all except 310-2 3/4OB)
Attributes
Amp Draw: .51 @ 12V .25 @ 24V
Application: 3/4″ Latchbolt
Baa Qualified: Yes
Base Material: Brass
Commercial Residential: Commercial
Configuration: Centered
Country of origin: USA
Faceplate Size: 9″ x 1-3/8″
Finish: 606/US4
Finish Family: Matte Brass
Fire Rated: Yes
Fire Rating: 3 Hours {A}
For Use With: Cylindrical Locks, Mortise Exit and Latch Locks
Frame Application: Metal or Wood
Function: Fail Secure
Grade: Grade 1
Holding Force: 1500 lbs.
Installation: Commercial
Keeper Size: 3/4″
Limited Warranty: 5 Years
Operating Voltage: 24 VDC
Origin: USA
Pack Height: 2.5″
Pack Length: 12.25″
Pack Qty: 1
Pack Volume: 183.75 in³
Pack Width: 6″
Series: 310 Series Electric Strikes
Ship Weight: 3.2 lbs.
Subtype: Electric Strikes
Type: Electric Strikes, Bolts, Magnets
Unit of Measure: Each
Resources
- 310 Series Electric Strikes Cut Sheet
- AA ESH Electric Strike Overview
- Electric Strike Selector Guide
