3′ Concealed Vertical Rod Smooth Case Exit Device – Von Duprin 626 Satin Chrome Finish

Description

Von Duprin 9847EO26D3 3′ Concealed Vertical Rod Exit Device, Satin Chrome Finish

Von Duprin 9847EO26D3 3′ Concealed Vertical Rod Smooth Case Exit Device features an innovative design that prioritizes safety and reliability in public buildings. With concealed vertical rod latching, this exit device is engineered for exit-only functionality, providing a secure means of egress without trim. The deadlocking latchbolt ensures enhanced security and optimal performance while maintaining standard device costs. Constructed from forged brass and finished in a sleek satin chrome (626), the device is not only durable but also visually appealing. It is compatible with 1-3/4″ and 2-1/4″ thick metal or wood doors, making it versatile for various installations. The included screw pack simplifies installation, while The Quiet One® fluid damper significantly reduces noise during operation, enhancing user experience. Measuring 33″ in overall length, with a head size of 8″ x 2-3/4″, this device accommodates standard 3′ doors. UL listed for safety, the Von Duprin 9847EO26D3 is backed by a limited 10-year mechanical and 3-year electro-mechanical warranty, ensuring long-lasting performance with minimal maintenance. Trust in Von Duprin’s legacy of quality and security for your architectural hardware needs.

3′ Concealed Vertical Rod Smooth Case Exit Device 626 Satin Chrome Finish

A mainstay in public buildings for decades Von Duprin’s safety products are known for their unparalleled quality and performance. From innovative exit devices to electronic access control solutions and accessories, Von Duprin never compromises when security is at stake. In fact, an independent study of more than 100 commercial facilities across the U.S. documented that Von Duprin exit devices require significantly less maintenance over a 30-year period than any other brand. The quality of Von Duprin’s exit devices provides confidence and peace of mind in critical moments.

• Includes Screw Pack for 1-3/4″ (44mm) and 2-1/4″ (57mm) Thick Metal or Wood Doors
• The Quiet One® Fluid Damper Decelerates the Pushpad on Its Return Stroke and Eliminates Most Noise Associated with Exit Device Operations
• Concealed Vertical Rod Latching
• Deadlocking Latchbolt Provides Security and Improved Performance at Standard Device Cost.
• Exit Only, No Trim

Attributes

Application: CM

Category: Exit Devices

Clazz: VD

Color: Satin Chrome

Country of Origin: Usa

Device Length: 33″

Device Type: Vertical Rod Device

Dimension: 33″ Overall Length, 8″ x 2-3/4″ Head, 2-1/4″ x 2-1/4″ Bar, 3-13/16″ Projection

Door Thickness: 1-3/4″

Door Width: 3′ Door

Finish: Satin Chrome

Finish Code: 626 (US26D)

Fire Rated: No

Function: Exit Only

Grade: Grade 1

Hazardous Material: NO

Includes Cylinder: No

Item Class : 3′ Concealed Vertical Rod Smooth Case Exit Device

Item Type Keyword: Exit

Limited Warranty: Limited 3 Year Warranty

Manufacturer Warranty: Limited 10 Year Mechanical and 3 Year Electro Mechanical Warranty

Material: Forged Brass

Minimum Stile Size: 4-3/4″

No Of Inners: 1

Number Of Inners: 1

Order_ Qty: 1

PO date: 2024-08-29

Product Dimension: 33″ Overall Length, 8″ x 2-3/4″ Head, 2-1/4″ x 2-1/4″ Bar, 3-13/16″ Projection

Series: 98 Series

Strike: 338 and 385A Strikes

Subcategory: Vertical Rod Exit Devices

Subtype: Vertical Rod Devices

Type: Exit Devices

Ul Listing Type: UL Listed
