Von Duprin 230L-03 526 RHR 22-Series Lever Trim 526 Instructions
Von Duprin 230L-03 526 RHR 22-Series Lever Trim 526 is a robust and stylish solution designed for commercial applications. This Grade 1 lever trim features a durable chrome powdercoat finish, ensuring both aesthetic appeal and long-lasting performance. Built with a classroom function, it promotes security while allowing for easy access, making it ideal for educational and public facilities. The 230L model comes with a cast zinc escutcheon measuring 3/4″ (19mm) in depth, combining strength with a sleek design. It is engineered for compatibility with 22 Series devices and can be installed on both metal and wood doors with thicknesses ranging from 1-3/4″ to 2-1/4″. This right-hand reverse trim is ADA compliant, ensuring accessibility for all users. With a limited warranty of 3 years and a design that adheres to ANSI A156.3 2008 standards, the Von Duprin 230L trim is built to withstand the demands of high-traffic environments. The lever design with escutcheon allows for seamless operation, while its reversible feature offers flexibility during installation. Weighing in at 5 lbs., this trim is both lightweight and sturdy, making it a reliable choice for your door hardware needs.
22-Series Lever Trim 526
Grade 1 Lever Trim, Classroom Function, 03 Lever with Escutcheon, Chrome Powdercoat Finish, Right Hand Reverse
The 230EO, 230DT, 230NL and 230TP have a heavy 10 gauge (2.4mm) steel escutcheon. The 230L has a cast zinc 3/4″ (19mm) depth escutcheon.
Several Von Duprin Trims are available to choose from.
Attributes
Manufacturer surcharge: 4.5%
Accessible: Yes
Ada Compliance: Yes
Ansi: A156.3 2008
Application: 22 Series Devices
Baa Qualified: Yes
Burglar Rated: No
Commercial Residential: Commercial
Country of origin: USA
Cylinder Type: 1-1/4″ Mortise
Design A: 03 Lever
Device Type: Trim
Door Material: Metal or Wood
Door Thickness: 1-3/4″ – 2-1/4″
Finish: 526
Finish Family: Matte Silver
Grade: Grade 1
Handing: Right Hand Reverse
Includes Cylinders: No
Installation: Commercial
Limited Warranty: 3 Years
Mechanical Function: Classroom
Origin: USA
Pack Height: 4.5″
Pack Length: 11″
Pack Qty: 1
Pack Volume: 297 in³
Pack Width: 6″
Restrictions: No
Reversible: Yes
Series: Von Duprin Trims
Ship Weight: 5 lbs.
Subtype: Exit Device Trim
Trim Design: Lever with Escutcheon
Trim Type: Lever
Type: Exit Devices
Unit of Measure: Each
