Description
Southwire G60004-23A 14 AWG 2 Conductor Bare Copper Twisted Plenum Fire Alarm Cable, Yellow, 1000ft
Southwire Company G60004-23A 14 AWG 2 Conductor Bare Copper, Twisted, Non-Shielded Plenum Fire Alarm cable is designed to meet stringent fire safety codes and regulations, making it an ideal choice for critical applications. This high-quality cable excels in fire protective signaling circuits, smoke detectors, voice communications, audio control, and initiating and notification circuits, adhering to Article 760 of the NEC. With a construction featuring 14 AWG solid bare copper conductors and insulated with LS-PVC, this cable is both durable and reliable. The twisted pair design enhances performance while maintaining flexibility, essential for installation in plenum spaces. The cable comes in a convenient 1000ft reel, allowing for easy handling and installation on larger projects. Weighing only 34 lbs per 1000 feet and boasting a nominal outer diameter of 192 mils, this cable is lightweight yet robust. Additionally, it includes a ripcord for effortless jacket stripping, streamlining the installation process. Available in various colors and optional features such as extruded stripes or composite cables, the Southwire G60004-23A offers versatility to suit a variety of project requirements. Ensure your fire alarm systems are equipped with the best safety solutions with this reliable Southwire cable.
14 AWG 2 Conductor Bare Copper, Twisted, Non-Shielded Plenum Fire Alarm, Yellow,1000ft Reel
Notice: The info below is not item specific.
Southwire’s fire alarm cables are manufactured in accordance to the most crucial fire safety codes and regulations, providing solutions for even the most critical of applications. These cables are superior for fire protective signaling circuits, as well as smoke detectors, voice communications, audio, control, initiating and notification circuits.
Features:
- Applications: Fire protective signaling circuits. Also for smoke detectors, voice communications, audio control and initiating circuits. Article 760 of the NEC. For use in plenum spaces.
- Available in 1000ft or 500 ft packages, reels, or pull-boxes where practicable.
- Optional: other colors, jackets with extruded stripes, and composite cables for multiple services, jacketed, or armored as permitted.
Construction:
- Conductor: 14 AWG solid bare copper
- Insulation: LS-PVC Colors: Black, red
- Shield/Drian: Unshielded
- Jacket: LS-PVC, 2 conductors, twisted and jacketed
- Ripcord: Yes
- Marker Tape: No
Specifications:
- No. of Conductors: 2
- Size (AWG or kcmil): 14 AWG
- No. of Strands: 1
- Nom. OD (mils): 192 mils
- Nominal Total Weight (lbs/1000′): 34 lbs/1000′
Attributes
Ship via: No UPS – Common Carrier Only
Alternate Codes: G60004-23A, G6000423A
Category: Access Control, CCTV Products, Wire & Cable, Wire & Power Supplies
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84″ or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
